Walbro 450 vs 535 vs DW400: Which Fuel Pump Do You Need?
At 80 psi and 13.5 volts, a Walbro 450 flows 341 liters per hour, a Walbro 535 flows 394, and a DeatschWerks DW400 flows 337. That is the whole Walbro 450 vs 535 vs DW400 debate in one line of bench data, and it is not the order most forum posts would have you expect.
This guide decides which of the three pumps belongs in your tank. We build our N54 and N55 low pressure fuel pump (LPFP) kits around all three and sell the bare pumps, so we have handled every one of them and have no reason to steer you toward the most expensive one.
Flow, current and pressure figures come from TI Automotive's published flow curves and DeatschWerks' DW400 tech sheet, owner results from SpoolStreet, Mustang6G and lateral-g threads, and prices from our store and DeatschWerks' list price. Prices vary by dealer.
The Short Answer
- Walbro 450 (F90000274), about $122: the default for a single pump build to about 575 whp on pump gas or 500 whp on E85 in an N54. Lightest current draw of the three at 17 amps at 60 psi.
- Walbro 535 (F90000295), about $166: the most flow of the three, 444 lph at 60 psi, for 650 whp pump gas or 550 whp E85 in a single pump N54 kit. No internal check valve, so plan for one in a dual setup.
- DW400 (9-401-1001), $239: flows within 3 percent of the F90000274 at 60 to 80 psi on the makers' own curves, with a 120 psi rating, a check valve on current units and a 46mm body that does not fit 39mm brackets. Pick it for a platform DeatschWerks makes a drop in module for.

Walbro 450 vs 535 vs DW400: The Numbers Side by Side
The Walbro 535 flows the most at every pressure, the Walbro 450 F90000274 and the DW400 are nearly tied from 60 to 100 psi, and the older Walbro 450 F90000267 falls off a cliff above 90 psi. Everything in the table below is from the manufacturers' own flow versus pressure sheets at 13.5 volts, converted from gallons per hour and rounded to the nearest liter.
| Pump (part number) | 40 psi | 60 psi | 80 psi | 100 psi | Amps at 60 psi | Max pressure |
|---|---|---|---|---|---|---|
| Walbro 450 (F90000267) | 430 lph | 381 lph | 328 lph | 206 lph | 16.9 A | 87 psi |
| Walbro 450 HP (F90000274) | 436 lph | 386 lph | 341 lph | 295 lph | 17.2 A | 112 psi |
| Walbro 525 (F90000285) | 448 lph | 404 lph | 361 lph | 317 lph | 20.6 A | 112 psi |
| Walbro 535 (F90000295) | 490 lph | 444 lph | 394 lph | 344 lph | 19.8 A | 112 psi |
| DeatschWerks DW400 (9-401) | 422 lph | 377 lph | 337 lph | 297 lph | 17.7 A | 120 psi |
Two notes on reading it. TI Automotive tested the F90000274 at 38 psi and the F90000295 at 42 psi for the first column, not exactly 40, and TI uses a mineral spirits test solvent on its bench while DeatschWerks does not name its test fluid, so treat differences under 5 percent as noise. The 535 at 80 psi is a real 15 percent over the 450 HP, and that is not noise.
The headline names are marketing. TI's own spec pages list the "525" at 470 lph and the "535" at 490 lph at 40 psi, and the "450" at 450 lph. DeatschWerks quotes the DW400 at 415 lph at 40 psi and 500 lph open flow, which is where the 400 comes from.
DeatschWerks' claim that the DW400 outflows the Walbro 450 by 31 percent from 70 to 100 psi is against the F90000267. Compare the 100 psi column and you can see why: 297 lph against 206 lph is a 44 percent gap. Against the high pressure F90000274 the two pumps trade places by a few liters, which is why our N54 kits use the 274.
What the Part Numbers Actually Mean
There are four Walbro pumps and three DW400 part number families hiding behind three nicknames, and the differences are pressure rating and check valve, not flow at street pressures. Walbro automotive pumps have been built by TI Automotive in Caro, Michigan for decades and now carry the TI name on the shell, so a "TI Automotive 450" and a "Walbro 450" are the same pump.
- F90000267, Walbro 450: 39/50 body, FLEX fuel rated, internal check valve, 87 psi maximum. The original and still the cheapest.
- F90000274, Walbro 450 high pressure: same body and flow to 80 psi, check valve, 112 psi maximum and a much flatter curve past 90 psi. This is the pump in our Walbro 450 F90000274 listing and our Stage 2 kits.
- F90000285, Walbro 525 "Hellcat": TI's dual channel DCSS impeller, 470 lph at 40 psi, check valve, 112 psi. Sold as the 39/80 flex fuel Hellcat style pump.
- F90000295, Walbro 535: the 525's sibling without the check valve, 490 lph at 40 psi, same 112 psi rating. TI's drawing revision literally reads "add no check valve to stamp." Ours is the Walbro 535 F90000295 listing.
- DW400, 9-401, 9-402, 9-403: one pump, three outlet options. 9-401 is the standard 3/8 inch hose outlet, 9-402 adds a 3/32 inch venturi outlet, 9-403 a 1/4 inch venturi outlet. The last four digits (9-401-1001 universal, 9-401-1041 Subaru, Nissan, Mazda and DSM, 9-401-1044 Fox body Cobra) pick the install kit.

The old story that the F90000274 is the "gas" 450 and the F90000267 is the "E85" 450 is wrong. TI lists both as FLEX fuel. The real split is 87 psi against 112 psi, and if your tuner ever raises low side pressure, the 274 is the one that keeps flowing.
Which Pump for Which Car and Power Level
A single Walbro 450 covers most tuned N54 and N55 street cars, the 535 buys about 15 percent more headroom, and the DW400 is the right call when DeatschWerks already makes a module for your chassis. Our kit ratings below are our own, based on the N54 running its 72 psi low side target on 93 octane or full E85; manufacturer ranges are crank horsepower across many platforms.
| Chassis and years | Engine | Pump or kit | Rated support | Cost |
|---|---|---|---|---|
| E82 135i, E90/E92/E93 335i, 2007 to 2013 | N54, N55 | Stage 2 kit, Walbro 450 | 575 whp gas, 500 whp E85 | $370 |
| E82 135i, E90/E92/E93 335i, 2007 to 2013 | N54, N55 | Stage 2.5 kit, Walbro 535 | 650 whp gas, 550 whp E85 | $430 |
| E82 135i, E90/E92/E93 335i, 2007 to 2013 | N54, N55 | Stage 2.5+ kit, DW400 | 700 whp | $510 |
| F30 335i, F22 M235i, F32 435i, 2012 to 2016 | N55, N20 | See our N55 lineup guide | 575 whp with a single 450 | Varies by stage |
| GD/GR WRX and STI, Evo 8 to X, S197 and S550 Mustang | Various | Bare pump plus platform install kit | 550 to 850 hp (TI, 450), 650 to 985 hp (TI, 525/535) | $122 to $260 |
Dual pump setups sit above this table. TI's ranges stop at 985 crank horsepower for a single DCSS pump, and an E92 owner on SpoolStreet puts two Walbro 450s at about 875 whp on E85. Our guide to wiring a secondary fuel pump covers the relay and trigger side of that.
If you are still deciding whether the LPFP is your limit at all, our N54 LPFP upgrade guide and the N55 fuel pump lineup walk through the stages, and our article on BMW low fuel pressure codes 29F2 and 29DC helps you confirm the pump is the problem before you spend. Four cylinder F30 328i, F32 428i and F22 228i owners should start with our N20 fuel pump guide, since most tuned N20 cars never need a pump at all.
Current Draw and the Stock Fuel Pump Controller
The Walbro 525 and 535 pull 2.5 to 3.5 amps more than a Walbro 450 at 60 psi on TI's bench, and that extra load lands on the BMW EKP module and the factory pump wiring, not on the pump. The DW400 sits in between at 17.7 amps, which is why some owners describe it as the easier pump on the electrical side.
On a stock N54 or N55 the EKP drives any of these pumps without wiring changes, which is how our kits go in. The trouble shows up at the edges: a worn EKP3 that already runs hot, a 15 year old ground, or a dual pump build that asks one controller to feed two 450s. An E87 135i owner on SpoolStreet watched a spare EKP3 hold a steady 52 psi and then get too hot to touch within minutes, and a vendor in the SpoolStreet pump shootout thread said the 525's roughly 4 extra amps over the 450's 18 could destabilize the stock controller.
DeatschWerks is blunt about it: its tech sheet says a 10 gauge hardwire kit is strongly recommended to keep full voltage at the DW400, and its launch article puts the pump at 16 to 20 amps at typical pressures. The 535 has no equivalent warning from TI, but it draws more than the DW400, so the advice applies to it too.
What Owners Actually Say
Owners who match the pump to a healthy fuel system and controller report years of trouble free running, and the complaints almost all trace to the bucket, the controller or a missing check valve rather than the pump itself. These are paraphrased from threads we read.
The 450 that would not hold pressure. An E87 135i owner on SpoolStreet with hybrid TD04L turbos put a Walbro 450 into the stock bucket with the factory venturi after the original pump sagged to 42 psi under load and threw the car into limp mode. The new pump started at 49 psi and slid to 39 psi within a minute. He replaced the low side pressure sensor and the regulator, found and fixed a leaking fitting, and still saw 52 to 37 psi, while a spare EKP3 held 52 psi but ran dangerously hot. The most experienced reply in the thread blamed his aging regulator and bucket plumbing, not the 450, and pointed out that factory regulators in that tank hat commonly fail at 10 to 12 years old.
- Walbro 535, then a 450 added: a 335is owner on SpoolStreet ran a single 535 bucketless for years with no issues on an EKP3. When he added a 450 on a Hobbs switch, startups developed a stumble, which he traced to the 535's missing check valve letting the rail bleed down. A check valve was the fix.
- DIY Walbro 450 on two E92 335is: an owner running a meth injected N54 built his own 450 install for about $130, did a friend's car the same way, and reports zero failures. His view is that two 450s cover about 875 whp on E85 and that the 525 and 535's extra current is not worth it in a dual pump build.
- DW400 in a 2019 Mustang Bullitt on E85: on Mustang6G, an owner whose factory pump died on E85 fitted a DW400 and found the only real catch is hard hot starts on older units with no check valve. DeatschWerks offered a free check valve install, or an inline valve for owners who did not want to pull the pump.
- Walbro 450 as the quiet one: a lateral-g member who found a Walbro 255 unbearably loud and an Aeromotive 340 flawed in other ways settled on a Walbro 450 and called it noticeably quieter, though he could not say why.
The negative we weigh most is the EKP heat report. A 450 should not cook a healthy EKP3, and a 535 on the same controller worked for the 1M owner in that thread, so a hot controller is a sign the controller or its wiring was already marginal.
Mistakes We See
The mistakes we see with these three pumps are fitment and plumbing mistakes, not pump failures, and every one of them is avoidable before the order goes in.
- Buying a DW400 for our 39mm bracket. The DW400 is 46mm. Our CNC billet 39mm bracket fits the Walbro 450, 525, 535, DW300 and DW420, and the listing says plainly it will not fit the DW400 or DW440.
- Running a 535 as a second pump with no check valve. The F90000295 has none. Without one, the primary pump pushes fuel backward through it at idle and you get long cranks and the start stumble the 335is owner above described. Use the F90000285 as the second pump or add an inline valve rated for E85.
- Choosing the F90000267 for a high pressure tune. Below 80 psi it is fine. At 100 psi it flows 206 lph against 295 lph for the F90000274 on TI's bench, and TI rates it to 87 psi maximum.
- Trusting the headline number. A "535" is a 490 lph pump at 40 psi and a 444 lph pump at the N54's 60 to 72 psi. Size the pump on the column that matches your fuel pressure, not the sticker.
- Blaming the pump for a tired bucket. A cracked venturi hose clamp, a 10 year old regulator or a clogged sock will drop pressure with any of these pumps in the tank. An E92 owner on SpoolStreet traced his low reading to the small clamp on the venturi hose and now holds 74 to 75 psi at idle.
- Buying a counterfeit Walbro. Fake 450s are common enough that Supra and turbo Ford forums keep spotting guides, and TI's site points buyers to its dealer list. Buy from an authorized dealer; we are one for every brand we carry, and in stock hardware ships fast.
Who This Is For (and Who Should Skip It)
These three pumps are for the owner whose logs show low side pressure dropping under boost or whose tune calls for more fuel than a stock lift pump delivers, which on an N54 usually means a Stage 2 or hybrid turbo car on E30 or richer.
Skip all three if you are on a Stage 1 pump gas map with pressure holding at target. The factory N54 and N55 pumps keep up with a bolt on car on 93 octane, and a 2018 Mustang GT owner on Mustang6G makes the same point about the S550: a Roush supercharged car keeps up at 650 rwhp on the stock pump before anyone needs a DW400. Spend the $370 to $510 on logging and a tune first.
Skip the 535 and DW400 specifically if your target is under 575 whp. You would be paying $44 to $117 more for flow and current you will never use. Skip the DW400 if you are building a custom hanger or surge tank around 39mm hardware, because nothing in that ecosystem fits a 46mm body.
If It Were Our Car
N54 E82 or E90, single pump, up to 575 whp: Walbro 450 F90000274, no hesitation. It is the cheapest of the three, the lightest on the EKP, and it has a check valve, so it works alone or as pump two later.
N54 or N55 single pump, 575 to 650 whp on pump gas or a full E85 car near 550 whp: Walbro 535. It is the only one of the three that flows meaningfully more than a 450 at 60 to 80 psi, and the 2 to 3 extra amps are fine on a healthy EKP. We would add an inline check valve if we ever planned to add a second pump.
Dual pump N54 past 700 whp: two Walbro 450s, both with check valves, a Y-line, and a relay trigger for pump two. Our secondary pump wiring guide is the one to read next.
Mustang, Corvette, WRX, Civic Si, Hemi: DW400, because DeatschWerks sells a drop in module or a chassis specific install kit for each of those, and a module that fits beats a pump that flows 15 percent more and needs a modified hanger. This is the one place we hedge, since a Walbro 450 with a platform install kit is about $117 cheaper and flows the same at 80 psi.

The Hardware That Goes Around the Pump
A bare pump needs a mount, an outlet fitting, a sock, a harness and sometimes a second pump's plumbing, and the parts list differs between the Walbros and the DW400. The Walbro 450, 525 and 535 share one 39/50 body with an 11mm barbed outlet, so they share hardware; the DW400 has a 3/8 inch hose outlet and a 46mm body, so it uses DeatschWerks' own install kits.
- Mount: our CNC billet 39mm bracket ($99.99) locks any of the three Walbros with a set screw for surge tanks and custom hangers.
- Outlet: the single outlet fitting ($28.99) or dual outlet fitting ($54.99) converts the Walbro barb to a 7.89mm quick connect with no clamps. Our 7.89mm fittings guide explains which to use when.
- Two pumps into one line: the dual pump Y-line ($29.99) joins two 7.89mm outlets into the factory hardline.
- Sock, harness and hose: TI's 400-1168 universal install kit covers the F90000267, 274 and 285; DeatschWerks' 9-1001 kit ($21) covers the DW400. Platform kits for Subaru, Evo, Mustang and E36 BMW live in our fuel pump fitment kits collection.

The bare pumps, modules and controllers live in our Walbro collection and DeatschWerks collection. Read our refund policy before ordering and confirm the body size and check valve, because a pump that has been in fuel cannot come back.
The Bottom Line
Pick the Walbro 450 F90000274 for a single pump build to 575 whp; it costs about $122, draws 17 amps at 60 psi and has a check valve. Pick the Walbro 535 when you need the extra 15 percent at 60 to 80 psi for 650 whp on gas or 550 whp on E85, and remember it has no check valve. Pick the DW400 when DeatschWerks makes a module for your chassis, not because it outflows the 450, because on the makers' own curves it does not. Skip the F90000267 if your tune runs past 80 psi. Whatever you choose, fix the bucket, regulator and controller first, since that is where almost every owner complaint about these pumps actually lives.
Frequently Asked Questions
How much horsepower can a Walbro 450 support?
TI Automotive rates both Walbro 450 part numbers (F90000267 and F90000274) for 550 to 850 crank horsepower depending on fuel and pressure. On a BMW N54 at its 72 psi low side target, our Stage 2 kit built around the F90000274 is rated for 575 whp on pump gas and 500 whp on E85.
What is the difference between the Walbro 450 and the Walbro 535?
At 13.5 volts and 80 psi, TI Automotive's own bench data shows the 535 (F90000295) flowing 394 lph against 341 lph for the 450 (F90000274), about 15 percent more, for roughly 2.5 amps more current. The 535 also has no internal check valve, while both 450s do.
Is the Walbro 535 E85 compatible?
Yes. TI Automotive lists the F90000285 (525) and F90000295 (535) as FLEX fuel pumps, the same rating as both 450 part numbers, so they run gasoline, E85 and ethanol blends. The DeatschWerks DW400 is E85 compatible as well, with carbon commutators and a fully encapsulated armature.
Does the DW400 have a check valve?
Current DW400 pumps do. DeatschWerks' tech sheet says the DW400 now includes an integrated check valve. Older units did not, which is why some owners report hard hot starts, and DeatschWerks offers an inline check valve for those pumps.
Is the DW400 a 39mm pump?
No. The DW400 has a 46mm body, 7mm wider than a standard 39mm pump, so it does not fit our CNC billet 39mm bracket or every stock hanger without modification. The Walbro 450, 525 and 535 are 39mm main housing pumps with a 50mm lower section.
Do I need to hardwire a Walbro 535 or DW400?
On a stock N54 or N55 the EKP module drives any of these pumps with no wiring changes, which is how our kits install. The 535 pulls about 20 amps at 60 psi and DeatschWerks recommends a 10 gauge hardwire kit for the DW400 in cars with marginal wiring, so check your chassis before trusting a 15 year old harness at full flow.
Which Walbro 450 part number should I buy, F90000267 or F90000274?
Buy the F90000274 if your fuel system runs above 80 psi or you ever plan to. TI rates it to 112 psi and it still flows 295 lph at 100 psi, where the F90000267 is rated to 87 psi and drops to 206 lph. Below 80 psi the two are within 4 percent of each other and the 267 is often cheaper.
