BMW Low Fuel Pressure Codes Explained: 29F2, 29DC, and When Your LPFP Is Dying

Jul 17, 2026Written by the OneFastShop team

Third gear, 5,200 rpm, and the 335i goes flat like someone pulled a plug. Half an engine lights up on the dash, the car limps home, and the scanner shows 29F2, 29DC and 2FBF. BMW's own service bulletin for those three codes lists eight possible causes, and the high pressure fuel pump is one line on the list.

This guide decides what each BMW 29F2 and 29DC fuel pressure code actually means, in BMW's wording, and then walks the same diagnosis order BMW's technicians use to tell a dying low pressure fuel pump (LPFP, the pump in the tank) from a dying high pressure fuel pump (HPFP, the pump on the engine) before anyone spends money. We build the drop-in N54, N55 and B58 LPFP assemblies pictured below and sell the lock ring tool the job needs, so we have handled every bucket in this article.

Code definitions, pressure thresholds and warranty history come from BMW Service Information bulletins SI B12 55 06 and SI B12 05 16 and from NHTSA recall records. Owner experiences come from SpoolStreet, Bimmerpost and SupraMKV threads. Kit prices are ours.

BMW E90 instrument cluster showing the check engine light during a low fuel pressure limp mode event
On the N54 the DME cuts injection and power when rail pressure collapses; code 29DC is that cut, not the cause.

Shop BMW Fuel Pumps

The Short Answer

  • 29F2 is "Fuel high-pressure, fuel pressure undershot" and 29DC is "Cylinder injection cut-out, pressure too low in high-pressure system." Both describe the rail. Neither names the pump that failed.
  • Log one third gear pull. If low side pressure sags below about 5 bar (72 psi) as rpm climbs, the LPFP, its filter or its control module is the problem. If low side holds and rail pressure collapses, suspect the HPFP.
  • Check the cheap parts first: fuel level, the EKP pump control module, the in-tank filter, the low pressure sensor and the venturi hose clamp inside the bucket. BMW's own test plan runs the low pressure test before the high pressure test.
  • Those hex codes are N54 codes. F chassis N55, N20 and B58 cars log six character codes such as 11A002 and 11A605 for the same failures.

Why BMW 29F2 and 29DC Fuel Pressure Codes Blame the Wrong Pump

The 29F2 and 29DC fuel pressure codes describe pressure in the high pressure rail, but the rail can only hold pressure the in-tank pump delivers, so a weak LPFP sets "high pressure" codes all day long. Every turbocharged direct injection BMW six, N54, N55 and B58 included, runs two pumps in series.

The electric LPFP sits in a plastic bucket inside the tank under the rear seat and feeds the engine at roughly 5 bar, about 72 psi. The cam driven HPFP on the side of the engine then raises that to around 200 bar, close to 2,900 psi, on the N54, N55 and Gen 1 B58, and to 350 bar on the B58TU. The high pressure pump is a plunger in a bore. It cannot make fuel, only squeeze what it is given.

So when the tank pump falls 1 bar short at 6,000 rpm, the rail falls hundreds of bar short, the DME sees rail pressure below target, and it logs a high pressure fault. BMW's SI B12 55 06 says exactly this: the listed causes for 29DC, 2FBF, 29F1 and 29F2 include a failed electric fuel pump, a clogged fuel filter, a bad low or high pressure sensor, a bad regulator, a bad volume control valve, a bad injector and a loose connector, alongside the HPFP itself.

What Each BMW Fuel Pressure Code Means, in BMW's Words

Four of these codes have definitions straight from a BMW of North America bulletin; the rest come from owner compiled ISTA readouts, and the table says which is which. The hex format (29xx, 2Fxx, 2Axx) belongs to the MSD80 and MSD81 DMEs on the N54, so these are the codes an E82 135i, E90 335i, E60 535i or E89 Z4 35i will show.

Code BMW definition Source What it usually means on the car
29DC Cylinder injection cut-out, pressure too low in high-pressure system SI B12 55 06 Rail pressure fell far enough that the DME stopped injecting. The classic N54 HPFP code, and the classic symptom of an LPFP that cannot keep up under boost.
29F2 Fuel high-pressure, fuel pressure undershot SI B12 55 06 Rail pressure dropped below the DME's target. Either pump can cause it; the log tells you which.
29F1 Fuel high-pressure, plausibility SI B12 55 06 Rail pressure does not match what the DME expects from the volume control valve. Often stored next to 29F2.
2FBF Fuel pressure on-release injection, pressure too low SI B12 55 06 Pressure was low when injection was released at startup. The long crank code; BMW's first fix for it was DME software, then the HPFP.
2AAF Fuel pump, plausibility ISTA readout quoted by owners; BMW SIB 13 05 09 covers it The low side missed its target. Points at the LPFP, its filter, or the EKP control module, and shows up often on tuned cars with upgraded pumps.
29F3 Fuel pressure sensor, electrical Owner compiled code list A circuit fault on the low pressure sensor, not a pressure problem. Check the sensor and its plug before any pump.
29E2 Fuel injection rail, pressure sensor signal Owner compiled code list The rail sensor signal is wrong or missing. Sometimes the sensor, often a real pressure collapse logged alongside 29DC.
2FBE Fuel pressure after engine stop Owner compiled code list The rail bled down after shutdown. A one time hit is noise; repeated with long cranks it points at the HPFP or a leaking injector.
29D9 Misfire with low tank fill level Owner compiled code list The DME saw misfires while the tank was low. Fill the tank before chasing anything else.

Two codes that get lumped in do not belong. 29E0 and 29E1 are mixture control faults for bank 1 and bank 2, and 2FBC is the volume control valve signal on the HPFP, per the same owner compiled lists. A generic OBD2 reader often shows only P0087, "fuel rail/system pressure too low," for all of the above, so a BMW capable tool is worth borrowing before the car goes anywhere.

The N55, N20 and B58 Use Different Code Numbers for the Same Failures

The N55, N20, N26 and B58 run newer DMEs that log six character codes, so an F30 335i or F22 M240i will never show 29F2. BMW's SI B12 05 16 for F chassis N55 cars lists 11A002, "Fuel high pressure, plausibility: pressure too low," and 11AC02, the cold start version, with 119404 for a stuck rail pressure sensor. An F32 435i owner on SpoolStreet posted 110001, "Cylinder injection shutdown for catalyst protection due to low fuel system pressure," 11A401, "High fuel pressure when injection is released: pressure too low," and 481B03, "Motor current too low," which is the EKP module complaining about the pump. B58 cars throw 11A605, "Fuel delivery rate too low," when the DME decides the tank pump cannot keep up.

Same two pump logic, same diagnosis order, different numbers. Translate the F chassis code to its N54 cousin and the rest of this article applies.

How to Tell Whether the LPFP or the HPFP Is Dying

A single logged pull separates the two pumps on any car with a low side sensor, which covers the N54 apart from the Z4, because the DME reads low side pressure and rail pressure at the same time and only one of them should move. Any car running MHD or bootmod3 can log both, a JB4 logs both at a slower rate, and ISTA or a good BMW scan tool shows them live on a stock car. Pick third gear, go wide open from about 2,500 rpm to redline, and read the two columns side by side. Our MHD datalog guide for the N54 covers the setup and what a healthy log looks like.

Signs the LPFP Is the Problem

A healthy low side reads about 5 bar, 72 psi, at light load on the N54 and holds there through the pull. BMW's bulletin sets the floor at 4.75 bar (69 psi) after a 20 second pump activation in ISTA, and calls low side swings between 5.0 and 7.0 bar under load a sign of a fuel delivery fault. If the number slides into the 50s or 40s as rpm and boost climb, the in-tank pump, its filter or its control module cannot move the volume, and rail pressure will fall with it a split second later.

The supporting clues all point at the tank. It is worse below a quarter tank, because the pump cools in the fuel around it, worse after a hot soak, and worse on E30 and up, because E85 carries roughly a quarter to a third less energy per gallon than gasoline and the pump has to move more volume for the same power. Owner compiled code lists note that 2AAF is "often triggered when running a tune," which is the stock pump being asked for volume it never had.

Signs the HPFP Is the Problem

If the low side holds a flat 72 psi while rail pressure drops hundreds of bar under load, the high pressure pump is the one giving up. The other HPFP signature is a 5 to 6 second crank on a cold start or after a hot soak with 2FBF stored, which is the exact complaint BMW describes in its bulletin. An E90 325i owner on Bimmerpost logged rail pressure holding about 200 bar, then dropping to 5 bar in limp mode: the rail had fallen to tank pump pressure, which is what an HPFP that has stopped pumping looks like.

Cars Without a Low Side Sensor Need a Gauge

The E89 Z4 35i has no low pressure fuel sensor, and BMW's bulletin has the technician tee a mechanical gauge into the supply line with a three way adapter before running the high pressure test. F chassis N55 cars are generally in the same boat: the N54's sensor is not cataloged for the F30 or F32, and F3x owners on SpoolStreet confirm there is nothing to log. If your log has no low side channel, the sensor is not there, and a 0 to 100 psi gauge teed into the supply line does the job.

If the car has not thrown a code yet and all you have noticed is a change in the pump's sound, start with our fuel pump whine guide, which covers the quarter tank test and what each kind of whine means before you ever pull a log.

The Diagnosis Order BMW Uses, and the Cheap Stuff It Catches

BMW's own test plan for these codes runs the low pressure test module first and the high pressure module second, so follow the same order and you will catch the cheap failures before you price a pump. Five things cause most of the false HPFP replacements we hear about.

  • Fuel level. Fill the tank, clear the codes, drive. Code 29D9 exists because a quarter tank and a hard corner uncovers the pickup.
  • The EKP module. The fuel pump control module (EKPS in ISTA, "EKP" to everyone else) sits under the rear seat on E chassis cars and drives the LPFP with a pulse width signal; owners call the two common revisions EKPM2 and EKPM3. An overheating module sags pump output with no code of its own, or stores 2AAF or a pump current fault on the N54 and 481B03 on F cars.
  • The in-tank filter. It lives in the bucket with the pump and strangles supply exactly like a dying pump. A 2020 X3 M40i on SpoolStreet lost rail pressure on a Stage 1 tune and threw 11A605; the cause was a clogged in-tank filter.
  • The low pressure sensor and its plug. Part 13 53 7 614 317 on the N54, mounted at the HPFP inlet. SpoolStreet owners report a failing one reading high, around 80 to 84 psi, and a 29F3 means its circuit, not the pump.
  • Hoses and clamps inside the bucket. An E87 N54 swap on SpoolStreet chased 39 to 49 psi through a new sensor and a new regulator before finding a loose silver clamp where the hose meets the venturi. Fixed, it read 74 to 75 psi.

The Fuel Gauge Stuck at Half a Tank

A fuel gauge that reads about half full no matter what you do means the level float inside the tank is hung up, usually on a line or the wiring running through the bucket. The float rides on the same assembly as the pump, so it is a mechanical fault inside the tank, not a cluster problem.

It matters here because the assembly has to come out to fix it, which is the moment to deal with a tired pump, and because a frozen gauge next to a marginal LPFP is how people run the tank to nothing and cook the pump. Treat a stuck gauge plus fuel pressure codes as one diagnosis.

OneFastShop N54 Stage 2 LPFP bucket assembly showing the top hat, float arm and in-tank filter
The float arm, filter and pump all live in one bucket, so a snagged float and a weak pump get fixed in the same visit.

The N54 HPFP Recall and Extended Warranty

BMW extended the N54 high pressure fuel pump warranty to 10 years or 120,000 miles and recalled about 130,000 N54 cars, and by model year every one of those cars is past the 10 year window. That history is why so many N54 owners assume any fuel code is "the HPFP again," and why so many pumps get replaced on reputation rather than data.

The sequence, from BMW's SI B12 55 06 and the NHTSA record:

  • Investigation: BMW begins investigating HPFP failures; NHTSA closes a preliminary investigation the same year.
  • Warranty extension, SI B13 03 09: the HPFP emissions warranty on model year 2007 to 2010 E60, E61, E90, E92 and E93, 2008 to 2010 E82 and E88, and 2009 to 2010 E89 and E71 N54 cars goes from 4 years or 50,000 miles to 10 years or 120,000 miles, transferable, all 50 states.
  • Recall: BMW announces the recall of roughly 130,000 N54 vehicles (2007 to 2010 335i, 2008 to 2010 135i, 535i, X6 xDrive35i, 2009 to 2010 Z4 sDrive35i) for pump replacement, DME software, or both, with about 40,000 cars expected to need a pump. Days after the announcement, dealers no longer needed head office approval to replace an HDP.
  • Final revision: the bulletin's last revision names 13 51 7 613 933 as the current pump with improved internal sealing, and adds a tool so the intake manifold no longer has to come off to change it.

Two things in that bulletin matter for a diagnosis. The 2FBF long crank fix in Situation I is a DME reflash, not a pump, if the low side reaches 4.75 bar on the ISTA activation test. And after an HPFP is replaced, the volume control valve adaptations have to be cleared and the car reflashed, or the new pump inherits the old pump's learned corrections.

Which Pump Fits Which BMW

The stock bucket part number changes with the chassis, and so does the lock ring, so match the assembly to the chassis before the whp number. Our three drop-in kits ship with the pump, top hat, float, filter and fittings assembled; the N54 and N55 kits are a direct replacement for the stock part with no wiring changes, and the B58 kit runs on the factory pump control with no external controller. Prices are ours; any pump sold elsewhere varies by dealer.

Chassis and years Engine Stock LPFP part Drop-in upgrade (our rating) Price
E82/E88 135i 2008 to 2010, 1M 2011; E90/E92/E93 335i 2007 to 2010, 335is 2011 to 2013 N54 16 14 7 163 298 N54 Stage 2, Walbro 450, 575 whp pump gas or 500 whp E85 $370
E82/E88 135i 2011 to 2013; E90/E92/E93 335i 2011 to 2013; E84 X1 35i 2013 to 2015 N55 16 14 7 163 298 Same N54 Stage 2 bucket fits (E chassis N55 shares it) $370
E60/E61 535i 2008 to 2010 N54 16 11 7 373 521 E60 N54 Stage 2, Walbro 450, 575 whp pump gas or 500 whp E85 $500
E89 Z4 35i 2009 to 2016; E71 X6 35i N54 Chassis specific Not covered by our kits; stock replacement or a chassis specific build Varies
F22/F23 M235i 2014 to 2016, F87 M2 2016 to 2018, F30/F31/F34 335i 2012 to 2015, F32/F33/F36 435i 2014 to 2016 N55 16 11 7 243 975 F series N55/N20 Stage 2, Walbro 450, 575 whp pump gas or 500 whp E85 $390
F22 228i, F30 320i/328i, F32/F36 428i, 2012 to 2016 N20/N26 16 11 7 243 975 Same F series Stage 2 bucket $390
F20/F21 M140i 2016 to 2019, F22/F23 M240i 2017 to 2021, F30/F31 340i 2016 to 2018, F32/F33/F36 440i 2017 to 2020 B58 Gen 1 16 11 7 344 066 F series B58 Stage 3 brushless, 850 whp E85 or 1,000 whp race gas $575
G20 M340i, G29 Z4 M40i, A90 Supra, any G chassis B58 / B58TU Different tank and bucket Our B58 kit does not fit; stock replacement or a G chassis specific pump Varies

The whp ratings are ours; the Walbro 450 vs 535 vs DW400 guide has the flow curves behind them. Above 575 whp the N54 moves to a dual pump bucket (our Stage 3 at $710, Stage 3.5 at $770) and the F series N55 to a dual Walbro 450 bucket at $760; the N54 LPFP stage guide and N55 LPFP lineup guide cover those. The E60, E89 and E71 use different buckets than the E8x and E9x, so our E8x/E9x kits do not fit them. The E60 and E61 535i take our three E60 kits instead, from $500, and use the same lock ring tool.

What Owners Actually Say

Owners who logged before buying parts fixed their cars for the price of a clamp or a module; the ones who replaced the famous part first spent four figures and kept the codes. These are paraphrased from the threads, with the forum named and nobody's handle.

The $780 pump that fixed nothing. A 2008 335i N54 automatic on SpoolStreet started with 29F1 and a misfire code, then shook and dropped into limp mode a few seconds into every hard pull while the rail fell to low side pressure and the AFR went lean. The owner's own log showed the LPFP holding a steady 72 psi until the rail started hunting. A new HPFP, about $780, changed nothing. A new rail pressure sensor changed nothing. A new low pressure sensor added 2AAF to the list. Sixteen months in, a dealer found the real cause: an incorrect, slightly too long injector bracket bolt had damaged the head. Every part replaced on the way had tested fine in the log the whole time.

E9x 335i, Stage 2 Walbro 450, SpoolStreet. The EKP module overheated on the bigger pump's draw and low side sagged to about 67 psi, starving the HPFP and causing a misfire. A replacement module, coded to the car, brought it to 72 to 76 psi and smoothed the post shift timing drops. Not a clean win: tip-in at wide open throttle still swung rich then lean while the HPFP caught up, so the module fixed the supply and exposed the next limit.

N54 swapped E87, Walbro 450 in the stock bucket, SpoolStreet. Low side started at 49 psi and fell to 39 psi within a minute, with an intermittent 2AAF. A new low pressure sensor did nothing. A new regulator in the tank hat did nothing. A loose clamp where the hose meets the venturi in the bucket was the whole problem; once tightened the car held 74 to 75 psi.

F32 435i N55, stock, SpoolStreet. Random limp mode and shutdowns with 11A002, 110001, 11A401 and 481B03 that cleared on a restart; the dealer could not reproduce it. Dorch Engineering, which makes HPFP upgrades, told the owner a pump fault does not clear with the memory and pointed at the EKP or LPFP, with a mechanical gauge on the supply line since the car has no low side sensor. The thread ends without a confirmed fix.

E90 325i N53, Bimmerpost. Not a turbo car, but the same MSD81 codes, 29F2 and 2FBF, with rail pressure falling from about 200 bar to 5 bar in limp mode while the low side stayed stable. Rail sensors, injectors and a non genuine HPFP did not cure it; a used genuine pump did. That is the HPFP signature in one line.

Mistakes We See

  • Replacing the HPFP because the code says "high-pressure." The code describes where the pressure was measured, not where it was lost. One pull with both channels logged costs nothing; the SpoolStreet owner above paid about $780 for an HPFP the log had already cleared.
  • Trusting a low side reading that looks high. Owners on SpoolStreet report failing N54 low pressure sensors reading 80 to 84 psi while the pump is actually struggling. If the number is above target and the car still falls flat, suspect the sensor before celebrating.
  • Diagnosing on a quarter tank. The pump cools in fuel and the pickup uncovers in corners. Fill it, then log it; 29D9 is BMW telling you the tank was low when the misfires hit.
  • Upgrading the pump and ignoring the module. A Walbro 450 draws more current than the stock pump and a tired EKPM2 can overheat and sag with it. Budget for the module on a tuned E chassis car, and expect to code a replacement.
  • Chasing 2FBF with parts. On an N54 with only 2FBF and a long crank, BMW's first step is the 20 second pump activation test; if it reaches 4.75 bar, the fix is DME software, not hardware.
  • Skipping the adaptation reset after a pump. BMW's procedure after an HPFP clears the volume control valve adaptations and reflashes the DME. A new pump running old corrections throws 29F1 for no mechanical reason.

Who This Is For (and Who Should Skip It)

This diagnosis is for any N54, N55, N20 or B58 owner with a fuel pressure code who can log a pull or borrow a gauge, and the pump upgrade at the end of it is for the tuned or ethanol fueled car whose stock pump has run out of volume. If the car is stock, staying stock, and the low side sagged because the 15 year old pump is worn, a stock replacement bucket solves it and costs less.

Skip the LPFP upgrade entirely if your log shows the low side holding 72 psi to redline, because the problem is downstream and a bigger tank pump will not touch it. Skip it if the car is an E89 or E71, where our kits do not fit, and skip the B58 kit if the car is any G chassis or a Supra. And if the only code is 2FBF with a long crank on an N54, try the software path before you buy anything at all.

If It Were Our Car

N54 E82 or E9x with 29DC or 29F2 under boost: fill the tank, log one third gear pull in MHD, and read the low side column. Low side falling away from 72 psi as rpm climbs means the bucket comes out, and if the car is tuned or ever will be, it goes back in with a Stage 2 Walbro 450 rather than another stock pump that will fail the same way at the same power level. Holding 72 psi with a collapsing rail means the HPFP, with the adaptation reset afterwards.

F chassis N55 or N20 with 11A002: a gauge on the supply line first, because there is probably no sensor to log. If line pressure is fine, HPFP; if it is low, the pump and the EKP, and the fix on a tuned car is the F series Stage 2 bucket plus a healthy module. Our N20 fuel pump guide covers when the four cylinder 228i, 328i and 428i actually need that upgrade.

B58 F chassis with 11A605: check the in-tank filter and the EKP wiring before anything else, since the one solved thread we found was a clogged filter. If the pump is genuinely out of volume on E50 and up, the brushless Stage 3 bucket, which the B58 Stage 3 brushless article covers in detail, runs on the factory control with no controller to wire.

The one place we hedge is a car with intermittent shutdowns and no sag in the log. That pattern has been the EKP module, a loose bucket hose, a bad sensor and, once, a wrong bolt in a cylinder head. Test the module and the wiring before any pump.

What the Job Takes

Changing a BMW in-tank pump is about a two hour driveway job in our experience, with one special tool, and the E chassis tool is the one most people are missing. The bucket sits under the rear seat cushion behind a large plastic lock ring, and the ring is where people break things.

OneFastShop two piece stainless fuel pump lock ring tool for BMW E chassis and MINI
The two bars stack into a plus sign and grip the E chassis lock ring at four points with a 3/8 inch ratchet; it does not fit the F or G chassis ring.
  • Lock ring tool, E chassis and MINI, about $23. Our fuel pump lock ring tool fits the E82, E9x, E60, E6x and R5x rings and turns with any 3/8 inch drive. Hammer and screwdriver methods crack rings and bend flanges. The lock ring walkthrough shows the four jaw setup. F and G chassis rings are a different design and need their own tool.
  • Seals. The N54 and N55 kits include the O-ring. The B58 kit does not include the two tank seal O-rings, 16 11 7 188 567 and 16 11 7 428 463; order them with the pump.
  • The module. Upgraded pumps draw more current, a weak or aged EKPM2 can overheat and shut down, and we recommend an EKPM3 with the N54 kit on a tuned car. A replacement module needs coding.
  • Safety. Cold car, ventilated space, no ignition sources, battery disconnected, system pressure relieved before the top hat comes off, and under a quarter tank so the bucket lifts out without a fuel bath.

We are an authorized dealer for every brand we carry, and in stock hardware ships fast. The house brand buckets carry a one year warranty; our warranty page and return policy have the terms.

Shop BMW LPFP Assemblies

The Bottom Line

29F2, 29DC, 2FBF and 2AAF all report the same event, fuel pressure below target, and only 2AAF names the side of the system that caused it. BMW's own bulletin lists eight causes for the "high-pressure" codes and runs the low pressure test first, so do the same. One logged third gear pull tells you which pump: low side sagging under 5 bar means the tank pump, its filter or its EKP module; low side flat at 72 psi with the rail collapsing means the HPFP. The N54 HPFP's recall and 10 year warranty are history now, so a pump on reputation is a pump on your dime. Fix the cheap things first, then put a bucket in the tank sized for where the car is going, not where it was.

Frequently Asked Questions

What does BMW fault code 29F2 mean?

BMW defines 29F2 as "Fuel high-pressure, fuel pressure undershot," meaning rail pressure fell below the DME's target. It names where the pressure was measured, not which pump lost it, so log low side and rail pressure together before replacing anything.

What does BMW fault code 29DC mean?

29DC is "Cylinder injection cut-out, pressure too low in high-pressure system." The DME stopped injecting because rail pressure collapsed. It is the classic N54 HPFP code, and a low pressure pump that cannot keep up under boost produces exactly the same collapse.

How do I know if my LPFP or HPFP is failing?

Log a third gear pull with MHD, bootmod3, a JB4 or ISTA. If low side pressure sags below about 5 bar (72 psi) as rpm climbs, the LPFP, filter or EKP module is failing. If low side holds while rail pressure drops, or the car needs 5 to 6 seconds of cranking when cold with 2FBF stored, suspect the HPFP.

What is the normal low pressure fuel pressure on a BMW N54?

About 5 bar, which reads around 72 psi in a log, at light load. BMW's service bulletin requires at least 4.75 bar (69 psi) immediately after a 20 second pump activation in ISTA, and treats swings between 5.0 and 7.0 bar under load as a fuel delivery fault.

Is the N54 high pressure fuel pump still under extended warranty?

No. BMW extended the HPFP warranty on model year 2007 to 2010 N54 cars to 10 years or 120,000 miles, whichever came first, and recalled about 130,000 cars. Every covered model year has now passed the 10 year limit.

Why did my codes come back after replacing the HPFP?

Because the HPFP can only pressurize what the tank pump feeds it. If the LPFP, its filter or the EKP module was the real limit, a new HPFP changes nothing. Also check that the volume control valve adaptations were reset after the swap, which BMW's procedure requires.

Why is my BMW fuel gauge stuck at half a tank?

The fuel level float inside the tank is hung up, usually on a line or wiring in the pump bucket. The float rides on the pump assembly, so the fix means pulling the assembly, which is the right time to replace or upgrade a tired LPFP in the same job.

What tool do I need to replace a BMW in-tank fuel pump?

A fuel pump lock ring tool that fits your chassis, a 3/8 inch ratchet, and basic hand tools. The E chassis and MINI ring takes our two piece tool; F and G chassis rings are a different design. Access is under the rear seat cushion.
