Clutch Masters FX400 Clutch Kit - Toyota Supra 7M-GTE / 1JZ R154 1986-1993 - 8-Puck Full-Face Sprung Ceramic
Clutch Masters FX400 Clutch Kit - Toyota Supra 7M-GTE / 1JZ R154 1986-1993 - 8-Puck Full-Face Sprung Ceramic, image 2
Logo Image
Clutch Masters FX400 Clutch Kit - Toyota Supra 7M-GTE / 1JZ R154 1986-1993 - 8-Puck Full-Face Sprung Ceramic
Clutch Masters FX400 Clutch Kit - Toyota Supra 7M-GTE / 1JZ R154 1986-1993 - 8-Puck Full-Face Sprung Ceramic, image 2
Logo Image

Clutch Masters FX400 Clutch Kit - Toyota Supra 7M-GTE / 1JZ R154 1986-1993 - 8-Puck Full-Face Sprung Ceramic

Clutch Masters SKU: CLM16063-HDCL
Price
18% OFF
Only 3 Left – Order Soon
Make sure this fits your vehicle Select your vehicle to confirm fitment before you order. Check
Shipping calculated at checkout.

Clutch Masters part number 16063-HDCL is the FX400 8-puck single-disc kit for the R154-equipped MKIII Supra. Like every FX400, it pairs the Power Plus I hi-leverage heavy-duty pressure plate with a sprung ceramic disc for a 170% increase in holding capacity over stock, rated race/street by Clutch Masters. The sprung hub gives moderate damping in high-torque applications, which Clutch Masters says makes it far more street friendly than a solid or rigid disc.

CL is Clutch Masters' segmented 8-puck ceramic disc, catalogued as FX400 (8-puck) and described by Clutch Masters as a ceramic full face design. It carries a marcel cushion between the disc linings, and that cushion is why Clutch Masters says this disc maintains minimal chatter and is designed for street driven vehicles. The sibling part 16063-HDC6 is the same FX400 system with the 6-puck paddle disc: more aggressive, solid with no marcel, and warned by Clutch Masters for chatter in first and reverse. Same holding capacity class, different manners. No flywheel is included in this kit. Clutch Masters notes ceramic discs are not recommended for stock or near-stock vehicles and are not intended to extend clutch life.

Specifications

Stage FX400 (8-puck)
Disc Material Premium ceramic
Disc Facings Segmented 8-puck, full-face design with marcel cushion
Sprung or Rigid Hub Heavy-duty sprung hub
Clamp Load Increase 170% increase in holding capacity over stock
Flywheel Required Flywheel not included; sold separately by Clutch Masters
Included Components Clutch disc, pressure plate, OEM-or-better release bearing, pilot bearing (when applicable), alignment tool, instruction card, decals
Street/Strip Use Race/street; Clutch Masters designs this disc for street driven vehicles
Part Number 16063-HDCL

Documents: Installation Instructions (PDF)  |  Break-In Instructions (PDF)

This part fits:

Year Make Model Submodel
1986-1993 Toyota Supra Turbo 3.0L 7M-GTE (R154 5-speed)
1989-1993 Toyota Supra Turbo 2.5L 1JZ (R154 5-speed)
