The DWR550c is DeatschWerks' compact bypass regulator for carbureted fuel systems, machined from 6061 aluminum and finished in black anodize. It flows up to 1000 lph and carries four -6AN inlet ports, so a single regulator can feed multiple carburetor lines, plus a -6AN return and a 1/8 in NPT gauge port. The body is ethanol compatible, so it runs on pump gasoline and E85 without swelling seals. This version ships with -8AN fittings and a pressure gauge already fitted, and DeatschWerks backs it with a limited lifetime warranty.
| Type | Compact adjustable bypass fuel pressure regulator, carbureted (DWR550c) |
| Flow | 1000 lph |
| Inlet Ports | 4 x -6AN |
| Return Port | -6AN |
| Gauge Port | 1/8 in NPT |
| Fittings Included | -8AN |
| Gauge | Pressure gauge included |
| Material | 6061 aluminum |
| Finish | Black anodized |
| Fuel Compatibility | Gasoline and ethanol blends |
| Warranty | Limited lifetime |
| Quantity | 1 |
| Part Number | 6-0550-FRB-88 |
