These two silicone hoses replace the cowl panel drains that carry rainwater out of the water box below the windscreen, a pair the factory built in rubber that hardens and cracks with age. Both are stepped, 35 mm inner diameter and 40 mm outer at the cowl end, tapering to 23 mm inner and 28 mm outer at the outlet, and are moulded entirely in high quality silicone with two reinforcement layers so they hold heat and pressure far longer than the originals. This is the black set; do88 offers the same kit in blue and red with no difference in performance. Hose clamps are not included, and do88 sells the matching stainless steel clamp set separately as clamp kit 56.
Specifications
| Type |
Silicone cowl panel drain hose kit |
| Position |
Cowl water box, left/rear and right/front drains |
| Kit Contents |
2 drain hoses (hose clamps sold separately) |
| Material |
Silicone with two reinforcement layers |
| Finish |
Black |
| Size |
35 mm ID / 40 mm OD at the cowl end, tapering to 23 mm ID / 28 mm OD at the outlet |
| OEM Replacement |
9133539, 1372572 (left/rear); 1372573 (right/front) |
| Pairs With |
do88 hose clamp kit 56, all stainless W4 clamps, sold separately |
| Warranty |
12 months against material defects and manufacturing errors |
| Quantity |
1 kit (2 hoses) |
| Part Number |
DO88-KIT56S |
This part fits:
| Year |
Make |
Model |
Submodel |
| 1992-1997 |
Volvo |
850 |
All engines |
| 1998-2005 |
Volvo |
C70 |
All engines |
| 1997-2000 |
Volvo |
S70 |
All engines |
| 1997-2000 |
Volvo |
V70 |
All engines |
| 1998-2000 |
Volvo |
XC70 |
All engines |
