Driveshaft Shop Level 4 AWD Conversion Rear Right Axle - Honda Civic 1992-2000

Driveshaft Shop Level 4 AWD Conversion Rear Right Axle - Honda Civic 1992-2000

Driveshaft Shop SKU: DSS510077
Price
In Stock – Ready to Ship
Shipping calculated at checkout.
Make sure this fits your vehicle Select your vehicle to confirm fitment before you order. Check

A rear axle for AWD converted Honda Civics, cut to length for the center mounted differential conversion mounts sold as the Hub City Performance kit. It uses the Driveshaft Shop two piece 300M outer CV design, a 300M axle bar, a Chromoly inner CV housing and a 300M splined differential stub, and it is built around the 25 spline rear differential from the 1988 to 1991 Honda wagon together with the 23 spline outer hubs this swap normally runs. This is the long right side shaft of the set, rated at 700HP in the X4 line and sold individually, with a one year warranty.

Specifications

Type Level 4 (X4) rear CV axle shaft for Honda AWD conversion
Position Rear, right (long)
Material 300M axle bar, 300M splined differential stub, Chromoly inner CV housing
Outer CV Two piece 300M design, 23 spline
Differential 1988-1991 Honda wagon 25 spline rear differential
Designed For Center mounted rear differential conversion mount (Hub City Performance)
Horsepower Rating 700HP
Quantity 1 (sold individually)
Warranty 1 year
Part Number 510077 (formerly RA2905X4)

This part fits:

Year Make Model Submodel
1992-1995 Honda Civic EG (AWD conversion)
1996-2000 Honda Civic EK (AWD conversion)
