Garrett GT2860RS "Disco Potato" ball-bearing turbocharger (part 836026-5014S), a popular sport-compact unit for 1.8-2.7L builds making roughly 250-360 hp. Pairs a 62-trim compressor (47mm inducer / 60mm exducer, 0.60 A/R) with a 76-trim turbine (54mm) in a T25/T28-inlet, 5-bolt Nissan-outlet, 0.64 A/R turbine housing, on dual stainless ball bearings, oil and water cooled. (This 5014S is the 0.64 A/R version; the 5013S uses the larger 0.86 A/R housing.)
| Type | GT2860RS ball-bearing turbocharger |
| Compressor | 62 trim (47mm inducer / 60mm exducer), 0.60 A/R |
| Turbine | 76 trim (54mm), T25/T28, 5-bolt outlet, 0.64 A/R |
| Bearing | Dual ball, oil + water cooled |
| Rating | ~250-360 hp (1.8-2.7L) |
| Part Number | 836026-5014S |
