The H&R Trak+ DRM Series is a 20mm bolt-on wheel adapter that mounts to the factory 5x120 hub and presents a fresh 5x120 wheel face 20mm further out per side, pushing the wheels flush with the fenders for a wider, more stable track. It stays fully hubcentric with a 64.1mm center bore and a full-contact hub face for even load distribution and lateral support. The adapter carries pressed-in 14x1.5 wheel studs and is machined from a proprietary H&R alloy with higher tensile strength than 6061-T6 billet aluminum. Made in Germany and sold as a pair.
| Type | Bolt-on wheel adapter (H&R Trak+ DRM Series) |
| Material | Proprietary H&R alloy (higher tensile strength than 6061-T6 aluminum) |
| Finish | Black |
| Size | 20mm (per side) |
| Bolt Pattern | 5x120 |
| Center Bore | 64.1mm (hubcentric) |
| Stud Thread | 14x1.5 |
| Quantity | Pair (2 adapters) |
| Part Number | 4075640SW |
Documents: Installation Instructions (PDF)
This part fits:
| Year | Make | Model | Submodel |
|---|---|---|---|
| 2017-2021 | Honda | Civic | EX |
| 2017-2021 | Honda | Civic | EX-L |
| 2017-2018 | Honda | Civic | EX-T |
| 2017-2021 | Honda | Civic | LX |
| 2017-2018 | Honda | Civic | LX-P |
| 2017-2020 | Honda | Civic | Si |
| 2017-2021 | Honda | Civic | Sport |
| 2017-2021 | Honda | Civic | Sport Touring |
| 2017-2021 | Honda | Civic | Touring |
| 2017-2021 | Honda | Civic | Type R |
| 2021 | Honda | Civic | Type R Limited Edition |
