The Wilwood Forged Narrow Superlite 4R rear big brake kit pairs forged billet aluminum four-piston calipers with 12.88 inch vented rotors and BP-10 street performance pads. It retains full use of the OE parking brake, master cylinder output, and ABS where equipped, making it a complementary rear upgrade for 13 inch and larger front brake systems. Optional drilled rotor faces and caliper finishes let builders match style and performance.
Specifications
| Type |
Rear big brake kit (Forged Narrow Superlite 4R) |
| Caliper |
Forged billet aluminum Narrow Superlite 4R |
| Pistons |
4 |
| Rotor Diameter |
12.88 in |
| Rotor Style |
Cross-drilled, vented |
| Pad Compound |
Wilwood BP-10 street performance |
| Position |
Rear |
| Finish |
Red |
| Parking Brake |
Retains OE parking brake |
| Part Number |
140-10471-DR |
This part fits:
| Year |
Make |
Model |
Submodel |
| 1970,1977-1982 |
Chevrolet |
Corvette |
Base |
| 1982 |
Chevrolet |
Corvette |
Collector's Edition |
| 1978 |
Chevrolet |
Corvette |
Indianapolis 500 Pace Car |
| 1978 |
Chevrolet |
Corvette |
Silver Anniversary Edition |
| 1975-1976 |
Chevrolet |
Corvette |
Stingray |
