MagnaFlow OEM-Grade vs CARB-Grade: Which Catalytic Converter Is Legal in Your State?
Across the 3,221 direct-fit catalytic converters in our catalog, the median MagnaFlow CARB-Grade unit costs $1,420 and the median HM-Grade unit costs $605. Same stainless body, same factory flanges, more than double the money. The difference is a California certificate and a heavier load of precious metal, and in four states that certificate decides whether the part can go on the car at all.
This guide settles MagnaFlow OEM-Grade vs CARB-Grade, plus the HM-Grade and Standard-Grade options in between: what each label means, which states require a CARB converter, when federal rules let you replace a converter in the first place, and which grade keeps the check engine light off.
Grade definitions and fitment come from MagnaFlow's catalog and its converter selection guide. State rules come from CARB Executive Orders and the New York DEC, Colorado CDPHE and Maine DEP pages, and the federal rules from the EPA's aftermarket converter policy. Prices are our storefront prices in US dollars, and they vary by dealer. This is a summary of published rules, not legal advice.
One converter per grade
Authorized MagnaFlow dealer. In stock orders typically ship within 1 to 3 business days. Four examples; the full direct-fit and universal lines are linked above.
The Short Answer
If the car is registered in California, Colorado or New York, only a CARB-Grade converter whose Executive Order lists your vehicle is legal. Maine requires it on 2001 and newer gasoline cars certified to CARB or EPA 50-state standards. Everywhere else, MagnaFlow's federal grades are legal: OEM-Grade or HM-Grade on 1996 and newer OBD-II cars, Standard-Grade only on 1995 and older cars that have no catalyst monitor.
MagnaFlow OEM-Grade vs CARB-Grade: What the Four Grades Mean
A MagnaFlow grade tells you two things at once: how much precious metal is inside the converter, and which agency's rules it was built to meet. Three grades are federal (EPA) parts and one is a California (CARB) part, and the price climbs with the metal and the testing.
Standard-Grade is MagnaFlow's federal converter for pre-OBD-II vehicles, meaning 1995 and older. HM-Grade is spelled out by MagnaFlow as High-Metal (its product graphics also say Heavy Metal), so it is a loading level, not a high mileage grade. MagnaFlow builds it for 1996 and newer OBD-II vehicles with federal emissions systems and says some HM part numbers may also go on California-emissions vehicles registered outside CARB states. OEM-Grade carries the highest federal loading for what MagnaFlow calls OE-like performance, and its qualifier covers OBD-II vehicles with California or federal emissions systems, registered anywhere except California, Colorado and New York.
CARB-Grade, which MagnaFlow labels California Grade, is a different animal. Each part number is exempted by a CARB Executive Order (EO) after durability testing, carries a 5 year or 50,000 mile warranty, wears a permanent label with the EO number, and is legal only on the specific vehicles and engine families its EO lists.
| Grade | Built for | Legal to install | Emissions warranty | Median price, direct-fit | Median price, universal |
|---|---|---|---|---|---|
| Standard-Grade | 1995 and older, pre-OBD-II | Federal states only | 25,000 miles | $300 | $141 |
| HM-Grade | 1996 and newer OBD-II, mainly federal emissions | Federal states only | 25,000 miles | $605 | $241 |
| OEM-Grade | 1996 and newer OBD-II, federal or California emissions | Federal states only | 25,000 miles | $759 | $248 |
| CARB-Grade | Vehicles listed on its EO | All 50 states, required in CA, CO, NY | 5 years or 50,000 miles | $1,420 | $523 |
The medians come from our own MagnaFlow listings sorted by the grade in the title: 180 Standard, 585 HM, 991 OEM and 1,151 CARB direct-fit converters, plus 445 universals (41 Standard, 4 HM, 113 OEM and 287 CARB). The warranty column follows MagnaFlow's product pages for the federal grades and the CARB Executive Orders for the California grade. "Federal states" excludes California, Colorado and New York, and Maine has its own split, covered next.
Which States Require a CARB Converter
California, Colorado and New York require a CARB-approved aftermarket converter on every vehicle that needs one, Maine requires one on most 2001 and newer gasoline vehicles, and every other state follows the federal EPA policy. MagnaFlow's guide puts the deciding rule plainly: legality follows the state where the vehicle is registered, not where you bought the part or where the car has been driven.
| Registered in | Rule | In force since | Vehicles covered | Federal converter allowed? |
|---|---|---|---|---|
| California | 13 CCR Section 2222(h), CARB EO required | EO label on every new converter sold since Jan 1, 2009 | All, matched to the EO list | No |
| Colorado | AQCC Regulation 20 | Jan 1, 2021 | Any model year | No, OEM or CARB only |
| New York | 6 NYCRR Part 218-7.2(c) | Jan 1, 2023 for all model years | Light and medium-duty gasoline, federal-only cars included | No |
| Maine | Maine DEP converter standards | June 1, 2018 | 2001 and newer gasoline, under 14,000 lb, CARB or EPA "50-state" certified | Yes on 2000 and older and on federal-only certified cars |
| All other states | EPA aftermarket converter policy | Aug 5, 1986, enforced from Jan 1, 1988 | All | Yes, in the grade the catalog lists |
New York is the strictest on paper. The DEC's guidance says federal converters are banned and that every aftermarket converter sold for any model year needs a CARB EO, federal-only cars included. Those federal cars are matched through a manufacturer's New York-specific catalog; if no CARB part fits, the installer uses an OEM converter or asks the DEC for help.
Colorado has adopted California's rule. CDPHE warns that CARB's online database only lists California and dual-certified vehicles, so for a federal-only car the converter maker's Colorado catalog is the first stop.
Maine is the one most buyers get wrong. MagnaFlow's guide describes it as 2001 and newer California-emissions vehicles, but the Maine DEP rule also covers EPA "50-state" certified vehicles, which are common. Federal-only certified cars and anything 2000 or older can still take a federal converter there. California, Colorado, New York and Maine all bar used or salvaged converters.
To find out which camp your car is in, read the Vehicle Emission Control Information (VECI) label under the hood, on a strut tower or on the radiator shroud. It states whether the car conforms to federal EPA rules, California rules or both, and it lists the engine family or test group a CARB EO is matched against. Photograph it before you order.
When You Are Allowed to Replace a Catalytic Converter
Under the EPA's aftermarket converter policy, which applies to every sale and installation, an aftermarket converter can go on in three situations only:
- The converter is missing when the vehicle comes in for exhaust work.
- A state or local inspection program has found the existing converter damaged or in need of replacement.
- The vehicle is past 5 years or 50,000 miles (8 years or 80,000 miles for 1995 and newer vehicles) and a legitimate need, such as a plugged converter or an unrepairable leak, has been established and documented.
The same EPA fact sheet says an aftermarket converter cannot replace one that is present and working, one under recall or warranty, or one on a vehicle returning from overseas use. The installer has to record the customer's name and address, the make, model year, mileage and reason on the invoice, keep invoices for 6 months and the old converter for 15 days, install the same type of converter in the same location, follow the maker's application catalog, and fill out the warranty card.
The federal minimum warranty on a new aftermarket converter is 5 years or 50,000 miles on the shell and end pipes, and 25,000 miles on emissions performance. Colorado, New York and Maine repeat the warranty test in their own words: the car must be beyond its original emissions warranty and the need must be documented. Maine's page puts that original coverage at 8 years or 80,000 miles, up to 15 years or 150,000 miles on hybrids and PZEV cars. If your converter failed inside that window, the automaker owes you the part, and you should not be buying one from anybody.
Why the Grade Decides Whether the Check Engine Light Comes Back
The check engine light comes back when a new converter cannot satisfy the OBD-II catalyst monitor, and the grade sets how much catalyst the converter has to satisfy it with. Every 1996 and newer gasoline car runs this monitor.
The monitor compares the oxygen sensor ahead of the converter with the one behind it. The front sensor switches rich and lean constantly; a healthy converter stores and releases oxygen, so the rear sensor reads much flatter. When the rear signal starts to mirror the front, the computer sets P0420 (catalyst efficiency below threshold, bank 1) or P0430 (bank 2). That threshold was calibrated around the factory converter.
A Standard-Grade converter is built for pre-OBD-II cars and can pass a tailpipe test while still failing that comparison on a newer engine. The EPA's fact sheet warns that newer OBD vehicles may not operate properly with some aftermarket converters, so the maker's catalog decides the part. HM and OEM-Grade units carry more metal for exactly this reason.
No grade fixes the engine that killed the old converter. Misfires dump raw fuel that overheats the substrate, a leaking head gasket coats it with coolant, and an engine burning oil poisons it. If the original converter died young, find out why first.
Direct-Fit vs Universal Converters
A direct-fit converter bolts in with the factory flanges, hangers and sensor bungs, while a universal is a bare converter body with plain pipe ends that a shop cuts and welds into the existing pipe. Both come in every grade.
The MagnaFlow 21-030 OEM-Grade underbody converter is a typical direct-fit: $712.00, catalogued by MagnaFlow for the 2012 to 2024 Jeep Wrangler 3.6L and the 2020 to 2023 Gladiator, and boxed with a flange gasket, two flat washers, a Torca clamp and two nuts. It replaces Mopar 68085148AB through 68085148AH. As an OEM-Grade part it is not for vehicles registered in California, Colorado or New York, and in Maine it only fits the federal-only or pre-2001 cases above.

A universal costs less as a part, with federal Standard-Grade universals in our universal converter collection starting around $90. It is the right call when no direct-fit is catalogued, when the exhaust is already custom, or when a muffler shop is doing the job anyway. In a CARB state a universal is legal only if its EO lists your vehicle. MagnaFlow's 333000 and 334000 series CARB universals, for example, run under EO D-193-161, which covers only 1995 and older non-OBD-II trucks with two converters per bank. Matching the pipe size is not enough.
The same logic applies to CARB direct-fits. The MagnaFlow 5461260 CARB-Grade converter for the 2003 to 2007 Honda Accord 2.4L is $1,050.00 and runs under EO D-193-140, which lists it for the Accord 2.4L LEV test groups, from 3HNXV02.4JBP in 2003 to 7HNXV02.4KKC in 2007. A California Accord with a different test group on its VECI label needs a part from a different EO line.

What Owners Actually Say
On TacomaWorld, the owner of a 2004 Tacoma 3.4L in California put in MagnaFlow CARB-compliant converters for about $600 for the pair, installed. The truck passed its first smog check after the swap easily and was still fine two years later, though the owner said plainly that he did not expect them to last half as long as the factory converters.
In another TacomaWorld thread, a 2006 Tacoma 4-cylinder owner had a shop weld in universal converters (brand not named) and had P0420 back after about 1,000 miles. He wrote that he should have trusted his own doubts about universals.
Three days. On GM-Trucks.com, a 2015 GMC Sierra 5.3L owner had GM replace the converters and Y-pipe at 79,000 miles, then saw P0420 and P0430 return at 100,000. New plugs, wires and Denso oxygen sensors did not clear them, and neither did a MagnaFlow 52642 OEM-Grade federal converter: the codes came back in about three days. In the same thread, a 2014 Sierra owner chased P0430 for about three weeks after new converters and sensors, and found a small misfire from plugs he believed were counterfeit. Original AC Delco plugs and wires fixed it.
On TahoeYukonForum, a Florida owner whose truck carried a California emissions label ran federal MagnaFlow 51578 converters with a new Y-pipe, paid $585, and called it less than half the price of OE. That pairing matches MagnaFlow's own rule: a California-emissions vehicle registered outside a CARB state can take a federal OEM-Grade part.
Emissions and the Law
This part is sold for off road and competition use only. Removing or defeating a catalytic converter on a vehicle driven on public roads violates the Clean Air Act, and many states inspect for it. Check your state and local laws before buying.
That statement applies to catless parts, such as our B58 catless downpipe; no catless pipe is a replacement converter in any state. A replacement converter is the legal side of the line. A MagnaFlow CARB-Grade converter is sold as emissions legal for your state only when its CARB Executive Order lists your vehicle, such as EO D-193-140 for the Accord unit above. MagnaFlow's federal grades are built to the EPA aftermarket converter policy and are not legal for sale or installation on vehicles registered in California, Colorado or New York.
Mistakes We See
- Buying by pipe diameter in a CARB state. MagnaFlow's own catalog notice says it is illegal in California, Colorado and New York to pick a converter on vehicle weight and engine size alone. Match the EO to the VECI label.
- Putting Standard-Grade on an OBD-II car. It saves a few hundred dollars and often buys a second converter. MagnaFlow catalogs Standard-Grade for 1995 and older vehicles.
- Skipping the diagnosis. A misfire, a coolant leak, an exhaust leak ahead of the rear sensor or a lazy rear sensor will set P0420 on a brand new converter, as the Sierra owners found.
- Moving the oxygen sensors. CARB's EO D-193-161 and New York's installer rules both require the sensors to stay in the factory location, position and orientation, so a universal has to be welded in with that in mind.
Who This Is For (and Who Should Skip It)
This guide is for owners of cars out of emissions warranty with a documented failure: a P0420 or P0430 that survives a proper diagnosis, a failed inspection, a rattling or plugged converter, or a stolen one.
Skip the purchase if the car is still inside 8 years or 80,000 miles, because the automaker's emissions warranty covers a defective converter. Skip it too if the engine is misfiring, losing coolant or burning oil; fix that first or the new converter dies on the same schedule. And if the car is registered in California, Colorado or New York, skip every federal grade no matter how cheap it is, because no shop can legally install it.
If It Were Our Car
- Registered in California, Colorado or New York: a CARB-Grade direct-fit whose EO lists the test group on the VECI label. If none exists, a CARB universal from an EO that lists the car, and failing that, the OEM converter.
- Maine, 2001 or newer, CARB or 50-state label: the same CARB answer.
- Federal state, 1996 or newer: OEM-Grade direct-fit. HM-Grade is a fair budget pick where MagnaFlow catalogs it for that engine and the emissions system on the VECI label.
- Federal state, 1995 or older: Standard-Grade direct-fit or universal. There is no catalyst monitor to satisfy.
- Custom exhaust or no direct-fit listed: a universal in the grade the state requires, welded in by a shop that keeps the sensor positions.
What It Pairs With
A converter job pairs with fresh gaskets (most MagnaFlow direct-fits include them), new nuts where the old ones are rusted, and a new downstream oxygen sensor if the original is old, since a slow sensor is a common reason the light returns. If you are planning other exhaust work, our downpipe vs cat-back guide explains where the converter sits in that decision.
We are an authorized dealer for every brand we carry, and in stock hardware ships fast. Not sure which part fits? Contact us with the SKU and your car's year, make, model, trim and engine before you order, and we will check it against MagnaFlow's application data and confirm fitment in writing. Legal status in your state is still yours to confirm, so run the EO and VECI label check above first. Returns follow our refund policy.
The Bottom Line
A MagnaFlow listing answers two questions: which agency's rules the converter meets, and how much catalyst it carries. Registration answers the first one. In California, Colorado and New York it has to be CARB-Grade with an EO that lists your car, and in Maine the same applies to most 2001 and newer vehicles. Everywhere else, OEM-Grade or HM-Grade suits an OBD-II car and Standard-Grade suits a 1995 or older one. Fix whatever killed the old converter before the new one goes in, or the grade will not matter.
Frequently Asked Questions
What is the difference between MagnaFlow OEM-Grade and HM-Grade?
Both are federal converters for 1996 and newer OBD-II vehicles registered outside California, Colorado and New York. HM stands for High-Metal and is mainly for federal emissions vehicles, while OEM-Grade carries the highest federal loading and also covers California-emissions vehicles registered in federal states. In our catalog the median HM-Grade direct-fit is $605 and the median OEM-Grade is $759.
Is a CARB catalytic converter required in New York?
Yes. New York DEC guidance says every aftermarket converter sold for any model year needs a CARB Executive Order, including on federal-only vehicles. Federal converters are not legal for sale or installation there.
Can I put a CARB-Grade converter on a car in a federal state?
Yes. MagnaFlow lists its California Grade converters as legal for sale in all 50 states for the vehicles on their Executive Orders. In a federal state the extra cost is optional rather than required.
Will a Standard-Grade converter turn on my check engine light?
On a 1996 or newer OBD-II car it can, because the catalyst monitor was calibrated around the factory converter and MagnaFlow builds Standard-Grade for 1995 and older vehicles. On those older cars there is no catalyst monitor, so Standard-Grade is the correct choice.
How do I know if my car has California emissions?
Read the Vehicle Emission Control Information label under the hood. It states whether the vehicle conforms to federal EPA rules, California rules or both, and lists the engine family or test group a CARB Executive Order is matched against.
Can I remove the catalytic converter instead of replacing it?
This part is sold for off road and competition use only. Removing or defeating a catalytic converter on a vehicle driven on public roads violates the Clean Air Act, and many states inspect for it. Check your state and local laws before buying.
Why did my new catalytic converter fail so quickly?
Converters rarely fail on their own. Misfires overheat the substrate with raw fuel, coolant from a head gasket leak coats it, and oil consumption poisons it, so fix the cause and replace tired oxygen sensors before the new converter goes in.
