Bilstein B8 5100 0-2.5in Lift Front Shock Absorber - Ford Ranger 2024-2026

Bilstein SKU: BIL24-336215
Price
28% OFF
In Stock – Ready to Ship
Make sure this fits your vehicle Select your vehicle to confirm fitment before you order. Check
Shipping calculated at checkout.

Details

BrandBilstein
SKUBIL24-336215
GTIN / UPC651860966182
Manufacturer Part Number24-336215

Product Information

The Bilstein B8 5100 (Ride Height Adjustable) replaces the OE front damper on trucks and SUVs that use a coilover style front suspension. Multiple snap ring grooves machined into the body let the spring seat sit at several heights, giving 0 to 2.5 in of front lift on this application while the factory spring stays in place. A 46mm digressive piston with self adjusting deflective disc valving controls the added travel and keeps the monotube fade free under load. The zinc plated body carries an 18mm shaft, measures 16.31 in collapsed and 21.30 in extended with 4.99 in of stroke, and the spring seat is included.

Specifications

Type B8 5100 (Ride Height Adjustable) monotube shock absorber
Position Front
Lift Range 0 to 2.5 in of front lift on OE springs
Finish Zinc plated
Piston Diameter 46mm
Shaft Diameter 18mm
Body Diameter 2.0 in
Collapsed Length 16.31 in
Extended Length 21.30 in
Stroke 4.99 in
Mounts Stem (upper), Crossbar (lower)
Spring Seat Included
Series B8 5100 (Ride Height Adjustable)
Design Monotube
Upper Mount Stem
Lower Mount Crossbar
Boot Included No
Spring Seat Included Yes
Country of Origin United States
Quantity per Vehicle 1
Quantity 1 (sold individually)
Part Number 24-336215
Warranty Limited Lifetime Warranty

Documents: Installation Instructions (PDF)  |  Safety Data Sheet (PDF)

This part fits:

Year Make Model Submodel
2024-2026 Ford Ranger Lariat
2024-2026 Ford Ranger XL
2024-2026 Ford Ranger XLT
