Bilstein SKU: BIL41-326084
Price
8% OFF
In Stock – Ready to Ship
Make sure this fits your vehicle Select your vehicle to confirm fitment before you order. Check
Shipping calculated at checkout.

The B8 8112 ZoneControl CR DSA+ is a direct fit, 3-way adjustable coilover corner module with a 2.65 in body and position sensitive damping. A triple piston design gives three stages of compression valving and two of rebound, while click adjuster knobs set low and high speed compression independently alongside an adjustable internal hydraulic bump stop. The threaded spring seat allows 0 to 3 in of ride height adjustment depending on application, and a 60mm remote reservoir with a bolt-on anodised chassis mount adds cooling capacity. This is the front left corner; Bilstein supplies the front right separately. Aftermarket upper control arms are required.

Specifications

Type 3-way adjustable monotube coilover corner module (Bilstein B8 8112 ZoneControl CR DSA+)
Position Front left
Body Diameter 2.65 in, 60mm piston, 22.0mm shaft
Adjustment 3 stages of compression valving, 2 of rebound, dual speed click adjusters, adjustable internal hydraulic bump stop
Ride Height Adjustment 0 to 3 in depending on application
Spring Rate 650 lb/in
Collapsed Length 18.90 in
Extended Length 25.20 in
Mounting 19.05mm lower eye, special upper mount
Finish EVO Grey damper, black spring
Weight 44.70 lb
Requires Aftermarket upper control arms
Series B8 8112 (ZoneControl CR DSA+)
Design Monotube
Upper Mount Special
Lower Mount Eye 19.05mm
Boot Included No
Spring Seat Included Yes
Country of Origin United States
Quantity per Vehicle 1
Quantity 1 (single corner)
Pairs With Bilstein 41-326091, front right corner module
Part Number 41-326084

Documents: Installation Instructions (PDF)  |  Product Specifications Sheet (PDF)  |  Safety Data Sheet (PDF)  |  Warranty (PDF)

This part fits:

Year Make Model Submodel
2014-2021 Toyota Tundra 1794 Edition
2007-2013 Toyota Tundra Base
2007-2021 Toyota Tundra Limited
2021 Toyota Tundra Nightshade
2010-2021 Toyota Tundra Platinum
2014-2021 Toyota Tundra SR
2007-2011, 2014-2021 Toyota Tundra SR5
2015-2017, 2019-2021 Toyota Tundra TRD Pro
2021 Toyota Tundra Trail
