BorgWarner S300SX-E S383 Turbo Super Core - 8780

BorgWarner AirWerks S300SX-E Super Core - 64.5mm Inducer, 87mm Compressor, 80mm Turbine

BorgWarner SKU: BWA13009097055
Price
20% OFF
In Stock – Ready to Ship
Make sure this fits your vehicle Select your vehicle to confirm fitment before you order. Check
Shipping calculated at checkout.

Details

BrandBorgWarner
SKUBWA13009097055
GTIN / UPC840232717280
Manufacturer Part Number13009097055

Product Information

This AirWerks S300SX-E super core is the complete rotating assembly and compressor stage of a BorgWarner S300SX-E turbo, with the S300SX-E line rated for 320-1000 hp. It uses an 87.37mm forged milled compressor wheel (64.47mm inducer) and a 79.76mm turbine wheel (73.37mm exducer) on journal bearings, a 360 degree thrust bearing, an integrated speed sensor port and a pre-machined boost port. The turbine housing is not included, so the A/R and flange are chosen separately to suit the engine.

Specifications

Type Super core (bearing and rotor assembly with compressor stage)
Series AirWerks S300SX-E
Power Range 320-1000 hp (S300SX-E line)
Compressor Wheel Forged milled, 64.47mm inducer, 87.37mm outer diameter
Turbine Wheel 73.37mm exducer, 79.76mm outer diameter
Service Kit 13007110005 (360 degree thrust bearing)
Not Included Turbine housing
Quantity 1
Part Number 13009097055

Documents: S300SX-E Spec Sheet (PDF)

Does the super core include a turbine housing?

  • No. The turbine housing is sold separately so the A/R and flange can be chosen for the build.

What wheel sizes does it use?

  • An 87.37mm compressor wheel with a 64.47mm inducer and a 79.76mm turbine wheel with a 73.37mm exducer.

What power range is the S300SX-E line rated for?

  • 320-1000 hp.
