BorgWarner S300SX-E S391 9180 Turbo Super Core - 66mm Inducer

BorgWarner AirWerks S300SX-E Super Core - 66.1mm Inducer, 91mm Compressor, 80mm Turbine

BorgWarner SKU: BWA13009097049
Price
20% OFF
In Stock – Ready to Ship
Make sure this fits your vehicle Select your vehicle to confirm fitment before you order. Check
Shipping calculated at checkout.

Details

BrandBorgWarner
SKUBWA13009097049
GTIN / UPC840232716740
Manufacturer Part Number13009097049

Product Information

This AirWerks S300SX-E super core is the complete rotating assembly and compressor stage of a BorgWarner S300SX-E turbo, with the S300SX-E line rated for 320-1000 hp. It uses a 91.44mm forged milled compressor wheel (66.11mm inducer) and a 79.76mm turbine wheel (73.37mm exducer) on journal bearings, a 360 degree thrust bearing, an integrated speed sensor port and a pre-machined boost port. The turbine housing is not included, so the A/R and flange are chosen separately to suit the engine.

Specifications

Type Super core (bearing and rotor assembly with compressor stage)
Series AirWerks S300SX-E
Power Range 320-1000 hp (S300SX-E line)
Compressor Wheel Forged milled, 66.11mm inducer, 91.44mm outer diameter
Turbine Wheel 73.37mm exducer, 79.76mm outer diameter
Service Kit 13007110005 (360 degree thrust bearing)
Not Included Turbine housing
Quantity 1
Part Number 13009097049

Documents: S300SX-E Spec Sheet (PDF)

Does the super core include a turbine housing?

  • No. The turbine housing is sold separately so the A/R and flange can be chosen for the build.

What wheel sizes does it use?

  • A 91.44mm compressor wheel with a 66.11mm inducer and a 79.76mm turbine wheel with a 73.37mm exducer.

What power range is the S300SX-E line rated for?

  • 320-1000 hp.
