Details
Product Information
This Brembo Prime Line front brake disc is an OE-equivalent UV painted ventilated rotor measuring 312 mm across and 25 mm thick, with a 23 mm minimum thickness, a 34 mm height and a 65 mm centering bore on a 5-hole hub (120 Nm tightening torque). The braking surface is high-carbon cast iron. The UV paint protects the outer edge and hub against corrosion. It carries ECE R90 homologation, ships one rotor per box and comes with fastening screws.
Specifications
| Line | Prime |
| Position | Front |
| Construction | Ventilated |
| Diameter | 312 mm |
| Thickness / Min Thickness | 25 mm / 23 mm |
| Height | 34 mm |
| Centering Bore | 65 mm |
| Bolt Holes | 5 |
| Tightening Torque | 120 Nm |
| Material | High-carbon cast iron braking surface |
| Coating | UV painted |
| ECE R90 | Certified |
| Quantity | 1 (sold individually) |
| Warranty | 24 months from delivery against defects in materials and workmanship |
| Part Number | 09.7880.11 |
This part fits:
| Year | Make | Model | Submodel |
|---|---|---|---|
| 2000-2006 | Audi | TT | Base |
| 2002 | Audi | TT Quattro | ALMS Edition |
| 2000-2006 | Audi | TT Quattro | Base |
| 2006 | Audi | TT Quattro | Special Edition |
| 2002-2006 | Volkswagen | Golf | GL |
| 2004 | Volkswagen | Golf | GL TDI |
| 2002-2006 | Volkswagen | Golf | GLS |
| 2004, 2006 | Volkswagen | Golf | GLS TDI |
| 2002-2006 | Volkswagen | Golf | GTI 1.8T |
| 2003 | Volkswagen | Golf | GTI 20th Anniversary |
| 2002 | Volkswagen | Golf | GTI 337 |
| 2002-2005 | Volkswagen | Golf | GTI VR6 |
| 2005 | Volkswagen | Golf | TDI |
| 2005 | Volkswagen | Jetta | 2.5 |
| 2004-2005 | Volkswagen | Jetta | GL |
| 2005 | Volkswagen | Jetta | GL TDI |
| 2004-2005 | Volkswagen | Jetta | GLI |
| 2004-2005 | Volkswagen | Jetta | GLS |
| 2005 | Volkswagen | Jetta | GLS TDI |
| 2004-2005 | Volkswagen | Jetta | TDI |
Documents: Technical Specifications | Assembly Instructions
Is this rotor sold individually or as a pair?
- It is sold individually, one rotor per box. Order two to replace both sides of the front axle.
What is the minimum thickness?
- The minimum thickness is 23 mm. Replace the rotor once it wears below that figure.
Does it come with hardware?
- Yes. Fastening screws are included in the box.
Is it a direct replacement for the original rotor?
- Yes. It is a Prime Line OE-equivalent disc with a 312 mm diameter, 25 mm thickness and 65 mm centering bore.
What warranty does it carry?
- It is covered for 24 months from delivery against defects in materials and workmanship.
