Details
Product Information
This Brembo Prime Line front brake disc is an OE-equivalent UV painted ventilated rotor measuring 348 mm across and 30 mm thick, with a 28.4 mm minimum thickness, a 73 mm height and a 79 mm centering bore on a 5-hole hub (120 Nm tightening torque). The braking surface is high-carbon cast iron. The UV paint protects the outer edge and hub against corrosion. It carries ECE R90 homologation, ships one rotor per box and comes with fastening screws.
Specifications
| Line | Prime |
| Position | Front |
| Construction | Ventilated |
| Diameter | 348 mm |
| Thickness / Min Thickness | 30 mm / 28.4 mm |
| Height | 73 mm |
| Centering Bore | 79 mm |
| Bolt Holes | 5 |
| Tightening Torque | 120 Nm |
| Material | High-carbon cast iron braking surface |
| Coating | UV painted |
| ECE R90 | Certified |
| Quantity | 1 (sold individually) |
| Warranty | 24 months from delivery against defects in materials and workmanship |
| Part Number | 09.A599.11 |
This part fits:
| Year | Make | Model | Submodel |
|---|---|---|---|
| 2009-2011 | BMW | 335d | Base |
| 2007-2013 | BMW | 335i | Base |
| 2009-2013 | BMW | 335i xDrive | Base |
| 2011-2013 | BMW | 335is | Base |
| 2007-2008 | BMW | 335xi | Base |
| 2013-2015 | BMW | X1 | sDrive28i |
| 2013-2015 | BMW | X1 | xDrive28i |
| 2013-2015 | BMW | X1 | xDrive35i |
Documents: Technical Specifications | Assembly Instructions
Is this rotor sold individually or as a pair?
- It is sold individually, one rotor per box. Order two to replace both sides of the front axle.
What is the minimum thickness?
- The minimum thickness is 28.4 mm. Replace the rotor once it wears below that figure.
Does it come with hardware?
- Yes. Fastening screws are included in the box.
Is it a direct replacement for the original rotor?
- Yes. It is a Prime Line OE-equivalent disc with a 348 mm diameter, 30 mm thickness and 79 mm centering bore.
What warranty does it carry?
- It is covered for 24 months from delivery against defects in materials and workmanship.
