Brembo Prime Front Brake Disc 340x30mm Plain Face - BMW 228i / 328i / 435i / 228i xDrive 2012-2021 - Composite

Brembo Prime Front Brake Disc 340x30mm Plain Face - BMW 228i / 328i / 435i / 228i xDrive 2012-2021 - Composite

Brembo OE SKU: BRE09.C397.13
Price
In Stock – Ready to Ship
Shipping calculated at checkout.
Make sure this fits your vehicle Select your vehicle to confirm fitment before you order. Check

The 09.C397.13 is a Brembo Prime Composite front disc for the BMW F2x/F3x cars: 340 mm diameter, 30 mm thick new, ventilated, 28.4 mm minimum thickness. Composite is Brembo’s pinned bi-material construction: an aluminium hat is joined to a high-carbon cast-iron braking ring by steel pins, so the ring can expand and contract against the hat instead of fighting it. That removes weight from the rotating assembly and keeps the ring flatter as it heats, while leaving the friction surface as iron. It is a different method from Dual Cast, where the aluminium is cast onto the ring in the foundry rather than pinned to it.

Read this one against its sibling before you order. Brembo builds 09.C397.13 and 09.C398.13 to exactly the same numbers, 340 mm diameter, 30 mm thickness, 28.4 mm wear limit, 73 mm height, 79 mm centering bore, 5 holes, same Composite construction, and very nearly the same vehicle list. The only difference between them is the face of the disc. This part, 09.C397.13, is the plain-faced one. 09.C398.13 is drilled and slotted. Nothing else separates them, so choose on the finish you want, not on dimensions. This disc also uses Pillar Venting Technology and is supplied with its hub fastening screws.

Specifications

Product Line Brembo Prime
Position Front
Construction Composite — aluminium hat pinned to a high-carbon iron ring
Braking Face Plain
Outside Diameter 340 mm
Thickness (New) 30 mm
Minimum Thickness 28.4 mm
Overall Height 73 mm
Centering Bore 79 mm
Bolt Holes 5
Disc Type Ventilated
Ventilation Pillar Venting Technology (PVT)
Type Approval ECE R90
EAN 8020584218501
Part Number 09.C397.13

This part fits:

Year Make Model Submodel
2014-2016 BMW 228i Base
2015-2016 BMW 228i xDrive Base
2017-2021 BMW 230i Base
2017-2021 BMW 230i xDrive Base
2016-2018 BMW 320i Base
2016-2018 BMW 320i xDrive Base
2014-2015 BMW 328d xDrive Base
2012-2016 BMW 328i Base
2014-2016 BMW 328i GT xDrive Base
2013-2016 BMW 328i xDrive Base
2016,2018 BMW 330e Base
2017 BMW 330e iPerformance
2017-2018 BMW 330i Base
2017-2019 BMW 330i GT xDrive Base
2017-2019 BMW 330i xDrive Base
2012-2015 BMW 335i Base
2014-2016 BMW 335i GT xDrive Base
2013-2015 BMW 335i xDrive Base
2016-2018 BMW 340i Base
2017-2019 BMW 340i GT xDrive Base
2016-2018 BMW 340i xDrive Base
2014-2016 BMW 428i Base
2015-2016 BMW 428i Gran Coupe Base
2014-2016 BMW 428i xDrive Base
2015-2016 BMW 428i xDrive Gran Coupe Base
2017-2020 BMW 430i Base
2017-2020 BMW 430i Gran Coupe Base
2017-2020 BMW 430i xDrive Base
2017-2020 BMW 430i xDrive Gran Coupe Base
2014-2016 BMW 435i Base
2015-2016 BMW 435i Gran Coupe Base
2014-2016 BMW 435i xDrive Base
2015-2016 BMW 435i xDrive Gran Coupe Base
2017-2020 BMW 440i Base
2017-2020 BMW 440i Gran Coupe Base
2017-2020 BMW 440i xDrive Base
2017-2020 BMW 440i xDrive Gran Coupe Base
2013-2015 BMW ActiveHybrid 3 Base
2014-2016 BMW M235i Base
2015-2016 BMW M235i xDrive Base
2017-2021 BMW M240i Base
2017-2021 BMW M240i xDrive Base
