Details
BrandBrembo OE
SKUBRE09.D424.11
GTIN / UPC8020584237564
Manufacturer Part Number09.D424.11
Product Information
This Brembo Prime Line rear brake disc is a ventilated OE equivalent rotor for the MLB Evo Audi range. It measures 350 mm across and 28 mm thick, wears to a 26 mm minimum, and stands 36 mm tall on a 68 mm centering bore with 5 holes. A water based UV paint protects the outer edges and hub against corrosion, and the disc carries ECE R90 type approval.
Specifications
| Type | Brake rotor (disc) |
| Line | Prime |
| Position | Rear |
| Construction | Ventilated |
| Diameter | 350 mm |
| Thickness / Min Thickness | 28 mm / 26 mm |
| Height | 36 mm |
| Centering Bore | 68 mm |
| Bolt Holes | 5 |
| Coating | UV painted (outer edges and hub) |
| ECE R90 | Certified |
| Fitment Notes | For vehicles equipped with 350 mm rear brake discs |
| Quantity | 1 (sold individually) |
| Warranty | 24 months from delivery against defects in materials and workmanship |
| Part Number | 09.D424.11 |
This part fits:
| Year | Make | Model | Submodel |
|---|---|---|---|
| 2020-2024 | Audi | A6 allroad | Premium Plus |
| 2020-2024 | Audi | A6 allroad | Prestige |
| 2019-2024 | Audi | A6 Quattro | Premium |
| 2019-2024 | Audi | A6 Quattro | Premium Plus |
| 2019-2024 | Audi | A6 Quattro | Prestige |
| 2019-2024 | Audi | A7 Sportback | Premium |
| 2019-2024 | Audi | A7 Sportback | Premium Plus |
| 2019-2024 | Audi | A7 Sportback | Prestige |
| 2019-2025 | Audi | A8 Quattro | L |
| 2020-2021 | Audi | A8 Quattro | L Plug-In Hybrid |
| 2022-2023 | Audi | e-tron Quattro | Chronos Edition |
| 2021-2023 | Audi | e-tron Quattro | Premium |
| 2019, 2021-2023 | Audi | e-tron Quattro | Premium Plus |
| 2019, 2021 | Audi | e-tron Quattro | Prestige |
| 2022-2023 | Audi | e-tron S | Premium Plus |
| 2022-2023 | Audi | e-tron S | Prestige |
| 2022-2023 | Audi | e-tron S Sportback | Premium Plus |
| 2022-2023 | Audi | e-tron S Sportback | Prestige |
| 2021-2023 | Audi | e-tron Sportback | Premium |
| 2020-2023 | Audi | e-tron Sportback | Premium Plus |
| 2020-2023 | Audi | e-tron Sportback | Prestige |
| 2017-2025 | Audi | Q7 | Premium |
| 2017-2025 | Audi | Q7 | Premium Plus |
| 2017-2025 | Audi | Q7 | Prestige |
| 2019-2025 | Audi | Q8 | Premium |
| 2019-2025 | Audi | Q8 | Premium Plus |
| 2019-2025 | Audi | Q8 | Prestige |
| 2024 | Audi | Q8 e-tron | Launch Edition |
| 2024 | Audi | Q8 e-tron | Premium |
| 2024 | Audi | Q8 e-tron | Premium Plus |
| 2024 | Audi | Q8 e-tron | Prestige |
| 2024 | Audi | Q8 e-tron Sportback | Launch Edition |
| 2024-2025 | Audi | Q8 e-tron Sportback | Premium |
| 2024 | Audi | Q8 e-tron Sportback | Premium Plus |
| 2024 | Audi | Q8 e-tron Sportback | Prestige |
| 2023-2025 | Audi | S6 | Premium |
| 2020-2025 | Audi | S6 | Premium Plus |
| 2020-2025 | Audi | S6 | Prestige |
| 2023-2025 | Audi | S7 Sportback | Premium |
| 2020-2025 | Audi | S7 Sportback | Premium Plus |
| 2020-2025 | Audi | S7 Sportback | Prestige |
| 2020-2025 | Audi | S8 | Base |
| 2020-2025 | Audi | SQ7 | Premium Plus |
| 2020-2025 | Audi | SQ7 | Prestige |
| 2020-2025 | Audi | SQ8 | Premium Plus |
| 2020-2025 | Audi | SQ8 | Prestige |
| 2024 | Audi | SQ8 e-tron | Premium Plus |
| 2024 | Audi | SQ8 e-tron | Prestige |
| 2024-2025 | Audi | SQ8 e-tron Sportback | Premium Plus |
| 2024 | Audi | SQ8 e-tron Sportback | Prestige |
Documents: Technical Specifications | Assembly Instructions
Is this sold as a pair?
- No. Each box holds one rotor, so order two for the rear axle.
Will it fit my car?
- It replaces 350 mm rear discs on the listed Q7, Q8, A6, A7, A8 and e-tron models.
When should it be replaced?
- A new disc is 28 mm thick; replace it at the 26 mm minimum thickness.
What warranty does it carry?
- 24 months from delivery against defects in materials and workmanship.
Shipping
- In stock orders typically ship within 1 to 3 business days.
- Standard, expedited, and overnight options at checkout.
- Oversized items ship by freight and take longer.
- Special order items follow a lead time we confirm with you individually before the order is committed.
- Backordered items ship as soon as stock lands. Lead times are manufacturer estimates and can change. Contact us for current ETAs.
- Need to cancel? Email us right away. Cancellations are not guaranteed once an order is in process. In-stock orders cancel free before they ship; a 6% fee applies only to confirmed backorders and special orders.
- International orders: prices do not include VAT, duties, or import fees. Your country charges these at import and they are the buyer’s responsibility.
Returns
- 30 days from delivery to request and ship back a return on new, uninstalled items in original packaging with all hardware.
- Standard returns: 8% restocking fee on the item price before tax and shipping. Shipping is not refunded in either direction. All waived if the item is defective or we made the error.
- Fitment guaranteed: select your vehicle above, or confirm fitment with us in writing before you order. If the part shows as a fit and it is wrong, the return is on us, even after installation. Otherwise, installed or used parts cannot be returned.
- Final sale: special orders, coilovers, electronics, engine internals, turbochargers, superchargers and turbo kits, unless defective or we sent the wrong item.
- Product images may be representative. The SKU and specifications in the listing are what ships.
- Email us for return authorization before shipping anything back.
