All-aluminum, TIG-welded high-performance radiator for the GR Corolla and GR Yaris, developed with race-team data as a true plug-and-play replacement for the factory unit. The 2-row, 42mm core uses CSF's exclusive B-Tube technology to raise heat transfer roughly 15% over conventional oval welded tubes, paired with new 5mm ultra-efficient multi-louvered fins for maximum surface area and airflow. The end tanks are designed with extra clearance for the CSF x Jackson Racing intercooler and other aftermarket intercoolers. CNC-machined mounting brackets, OEM-style inlet/outlet, pre-installed foam sealing strips, and a pre-plugged 1/8" NPT sensor port complete the drop-in fit.
| Type | High-performance all-aluminum radiator, TIG-welded |
| Core | 2-row, 42mm; CSF B-Tube technology (~15% more heat transfer) |
| Fins | 5mm tall ultra-efficient multi-louvered |
| Finish | Hand-brushed satin |
| Included | CNC-machined mounting brackets, OEM-style inlet/outlet, foam sealing strips, pre-plugged 1/8" NPT sensor port |
| Fit | Plug-and-play drop-in, no modifications |
| Part Number | 7233 |
| Warranty | 2-year limited warranty |
This part fits:
| Year | Make | Model | Submodel |
|---|---|---|---|
| 2023-2024 | Toyota | GR Corolla | Circuit Edition |
| 2023-2026 | Toyota | GR Corolla | Core |
| 2023 | Toyota | GR Corolla | Morizo Edition |
| 2024-2026 | Toyota | GR Corolla | Premium |
| 2025-2026 | Toyota | GR Corolla | Premium Plus |
