do88 Intercooler Kit, twin black units with hardware laid out

do88 Intercooler Kit - Porsche 911 Turbo / Turbo S (992.1) 2020-2024

do88 SKU: DOBICM-400
Price
Only 4 Left in Stock – Order Soon
Make sure this fits your vehicle Select your vehicle to confirm fitment before you order. Check
Shipping calculated at checkout.

Details

Branddo88
SKUDOBICM-400
Manufacturer Part NumberICM-400

Product Information

Complete charge cooling upgrade for the 992.1 Turbo, built on motorsport grade Garrett bar-and-plate cores 105 mm (4 in) thick with thin, densely stacked fins. Freeform cast aluminum end tanks carry machined 70 mm (2.75 in) connections, and both cores feed a central outlet tank towards the inlet manifold. Vacuum infused prepreg carbon ambient air guides replace the factory ducts to clear the thicker core and seal to the body. do88 measured 799 CFM at 0.125 bar (1.81 psi) pressure drop against 740 CFM for the OE assembly, 8 percent higher, and a 12°C (21.6°F) lower inlet air temperature over four consecutive full-throttle runs in a 757 hp Turbo S. The outlet tank carries two 1/8 NPT bungs for water/methanol injection.

Specifications

Type Air-to-air intercooler kit, Garrett Motorsport bar-and-plate cores
Core Thickness 105 mm (4 in)
Material Aluminum core with cast aluminum end tanks, prepreg carbon air guides
Inlet/Outlet 70 mm (2.75 in) machined connections
Airflow 799 CFM at 0.125 bar (1.81 psi) pressure drop, 8% over OE
Charge Air Temperature 36°C (96.8°F) vs 48°C (118.4°F) OE, 12°C lower
Ports 2x 1/8 NPT water/methanol injection bungs on the outlet tank
Included Two intercoolers, central outlet tank, carbon fiber ambient air guides with seals, silicone hoses, installation hardware
Quantity 1 kit (2 intercoolers)
Part Number ICM-400
OEM Replacement 992145805G, 992145816C, 992145817B, 992145928D, 992145927D, 992145737, 992145738

Documents: Installation Instructions (PDF)

This part fits:

Year Make Model Submodel
2020-2024 Porsche 911 (992.1) Turbo
2020-2024 Porsche 911 (992.1) Turbo S
