The HKS DCT Cooler Kit adds a dedicated fluid cooler to the R35 dual clutch transmission to hold gearbox oil temperature down under sustained track use. The 200 x 220 x 48.5 mm, 15 row core mounts inside the left front fender and is plumbed with AN-10 lines, with a dry carbon duct and air partition directing airflow through it. Because the core occupies the fender space, HKS supplies a replacement washer tank; capacity drops from 1.5 L to 1 L and the factory washer level sensor cannot be fitted. HKS recorded transmission oil temperature holding near 127°C (260°F) in track testing with the kit installed.
| Type | Dual clutch transmission fluid cooler kit (HKS DCT Cooler Kit) |
| Position | Left front fender mounted |
| Core Size | 200 x 220 x 48.5 mm, 15 rows |
| Lines | AN-10 |
| Material | Dry carbon cooler duct and air partition |
| Included | Cooler core, 4 core brackets, duct, air partition, replacement washer tank and hose, oil line attachment, 3 pipes, 4 hoses (665, 695, 515 and 465 mm), 2 fire sleeves, pipe and hose brackets, clamps and hardware |
| Installation Notes | Bumper modification is required. The replacement washer tank reduces capacity from 1.5 L to 1 L and does not accept the factory washer level sensor. Fitment on the GT-R NISMO is not confirmed by HKS |
| Quantity | 1 kit |
| Part Number | 27002-AN105 |
Documents: Installation Instructions (PDF)
This part fits:
| Year | Make | Model | Submodel |
|---|---|---|---|
| 2017-2019 | Nissan | GT-R | All |
