Mishimoto Front-Mount Intercooler - Ford Mustang EcoBoost 2015-2023 - Black

Mishimoto SKU: MISMMINT-MUS4-15BK
Price
9% OFF
In Stock – Ready to Ship
Make sure this fits your vehicle Select your vehicle to confirm fitment before you order. Check
Shipping calculated at checkout.

Details

BrandMishimoto
SKUMISMMINT-MUS4-15BK
GTIN / UPC748354019056
Manufacturer Part NumberMMINT-MUS4-15BK

Product Information

A direct-fit bar-and-plate intercooler for the 2015-2023 Mustang 2.3L EcoBoost that mounts in the stock location and works with the factory active grille shutters. Cast end tanks with an in-tank diverter on the hot side spread flow across a core that is 58% larger than stock, with 25% more internal volume and 165% more external fin surface area. It lowers intake air temperatures by 35°F with minimal pressure loss and installs in under two hours without removing the front bumper cover. The finish is stealth black.

Specifications

Type Front-mount performance intercooler
Core Bar-and-plate, TIG welded, cast end tanks with hot-side air diverter; 21.06 in L x 5.75 in H x 2.76 in thick; 58% larger core, 25% more internal volume, 165% more external fin surface area
Inlet / Outlet 2.56 in / 2.56 in
Overall Size 30.3 in L x 6.8 in H x 8 in W
Gains 35°F lower intake air temperature
Color Black
What's in the Box
  • (1) intercooler
  • (1) M6 x 1.0 x 20 mm flange bolt
  • (1) M4 x 0.7 x 12 mm button head bolt
  • (1) M4 lock washer
Fitment Notes 2.3L EcoBoost only; mounts in the stock location and works with the factory active grille shutters
Install Medium difficulty, under 2 hours, no bumper cover removal
Emissions Covered by CARB Executive Order D-759-23 for the 2015-2023 Ford Mustang 2.3L EcoBoost
Overall Length 30.3 in
Overall Height 6.8 in
Overall Width 8 in
Core Length 21.06 in
Core Height 5.75 in
Inlet 2.56 in
Outlet 2.56 in
Engine 2.3L EcoBoost
Chassis Codes S550
Quantity 1
Warranty Mishimoto Lifetime Limited Warranty
Part Number MMINT-MUS4-15BK

This part fits:

Year Make Model Submodel
2015-2023 Ford Mustang EcoBoost
2015-2023 Ford Mustang EcoBoost Premium

Documents: Installation Instructions (PDF)

Which Mustangs does it fit?

  • The 2015-2023 Ford Mustang with the 2.3L EcoBoost.

Do I have to remove the bumper?

  • No. It installs in under two hours without removing the front bumper cover.

Is it street legal in California?

  • Yes. It is covered by CARB Executive Order D-759-23 for the 2015-2023 Mustang 2.3L EcoBoost.

How much cooler does it run?

  • It lowers intake air temperatures by 35°F compared to stock.

Is there a warranty?

  • Yes, the Mishimoto Lifetime Limited Warranty.
