Details
BrandMishimoto
SKUMISMMOP-SPTM22
GTIN / UPC748354030204
Manufacturer Part NumberMMOP-SPTM22
Product Information
Mishimoto oil sandwich plate, a lightweight, CNC-machined billet 6061 aluminum plate that mounts between the engine block and oil filter to add an external oil cooler or sensors without modifying the block. High-flow design; backed by the Mishimoto Lifetime Warranty. M22 thermostatic plate with a built-in 185F (85C) thermostat (interchangeable with 160F or 200F) to regulate oil flow to the cooler for faster warm-up and cold-climate protection. 1/8in NPT plugged sensor port. Universal (M22 stainless center bolt).
Specifications
| Type |
Thermostatic oil sandwich plate |
| Thread |
M22 |
| Thermostat |
185F (interchangeable 160/200F) |
| Fitment |
Universal |
| Overall Length |
3.58 in |
| Overall Height |
3.67 in |
| Overall Width |
1.24 in |
| Mounting Hardware Included |
0 |
| Fitment Notes |
This sandwich plate was designed to only be used with an M22 Sandwich Plate Adapter |
| Part Number |
MMOP-SPTM22 |
