Mishimoto Performance Intercooler Kit, core with pipes laid out

Mishimoto Performance Intercooler Kit - Ford F-150 3.5L EcoBoost 2017-2020 - Black Core / Polished Pipes

Mishimoto SKU: MISMMINT-F35T-17KPBK
Price
9% OFF
In Stock – Ready to Ship
Make sure this fits your vehicle Select your vehicle to confirm fitment before you order. Check
Shipping calculated at checkout.

Details

BrandMishimoto
SKUMISMMINT-F35T-17KPBK
GTIN / UPC811580033896
Manufacturer Part NumberMMINT-F35T-17KPBK

Product Information

This kit pairs a black bar-and-plate performance intercooler with polished aluminum charge pipes for the twin-turbo 3.5L EcoBoost F-150 and second-generation Raptor. The intercooler has 77% more internal core volume and 163% more external fin surface area than stock on cast end tanks, lowering intake air temperature by 10°F (5.5°C), and it fits the stock intercooler fans without modification. Larger volume aluminum pipes replace the factory plastic piping with DuraCore silicone boots and constant-tension clamps, and the cold side pipe has a CNC quick-disconnect flange with a pre-installed O-ring plus a port that can be drilled and tapped for methanol injection or sensors.

Specifications

Type Intercooler and pipe kit
Core Bar-and-plate, all-aluminum TIG welded, cast end tanks; 77% more internal volume, 163% more external fin surface area; core 19.6 in x 9.4 in x 4.7 in thick, overall 29 in x 9.5 in x 7 in
Inlet / Outlet 2.5 in inlet, 3 in outlet
Pipes Aluminum, larger volume than the stock plastic pipes; CNC quick-disconnect cold side flange with pre-installed O-ring and spring clip
Color Black core, polished pipes
Gains 10°F (5.5°C) lower intake air temperature
What's in the Box
  • (1) intercooler with rubber trim
  • (1) bypass valve bracket
  • (1) aluminum cold side pipe with CNC quick-disconnect flange
  • (1) aluminum cold side pipe with CNC IAT sensor housing
  • (4) aluminum hot side pipes
  • (8) DuraCore silicone boots
  • (16) constant-tension worm gear clamps
  • Mounting and bypass valve hardware
Fitment Notes 3.5L EcoBoost engine only, including the second-generation Raptor. Fits the stock intercooler fans without modification. 27 in-lbs (3NM) recommended for all T-bolt and constant-tension T-bolt clamps. These clamps have an operating range of 18-35 in-lbs (2-4NM). Do not exceed the maximum torque rating of 35 in-lbs (4NM).
Install Medium difficulty; clamp torque 27 in-lbs (3 Nm), do not exceed 35 in-lbs (4 Nm)
Emissions Covered by CARB Executive Order D-759-6 for the 2017-2018 Ford F-150 Raptor 3.5L EcoBoost
Overall Length 29 in
Overall Height 9.5 in
Overall Width 7 in
Core Length 19.6 in
Core Height 9.4 in
Core Thickness 4.7 in
Inlet 2.5 in
Outlet 3 in
Engine 3.5L V6 EcoBoost
Quantity 1
Warranty Mishimoto Lifetime Limited Warranty
Part Number MMINT-F35T-17KPBK

This part fits:

Year Make Model Submodel
2017-2020 Ford F-150 King Ranch
2017-2020 Ford F-150 Lariat
2017-2020 Ford F-150 Limited
2017-2020 Ford F-150 Platinum
2018-2020 Ford F-150 Police Responder
2017-2020 Ford F-150 Raptor
2017-2020 Ford F-150 SSV
2017-2020 Ford F-150 XL
2017-2020 Ford F-150 XLT

Documents: Installation Instructions (PDF)

Does it fit the Raptor?

  • Yes. It fits the 2017-2020 F-150 3.5L EcoBoost, including the second-generation Raptor.

Does it fit the 2.7L EcoBoost?

  • No. It is for the 3.5L EcoBoost only.

Is it street legal in California?

  • CARB Executive Order D-759-6 covers this kit on the 2017-2018 F-150 Raptor 3.5L. The order does not list the other 2017-2020 F-150 3.5L trucks.

What torque should the clamps get?

  • 27 in-lbs (3 Nm), and no more than 35 in-lbs (4 Nm).

Is there a warranty?

  • Yes, the Mishimoto Lifetime Limited Warranty.
