Radium Engineering Fluid Lock Dual Catch Can Kit, two canisters with hoses and fittings

Radium Engineering Fluid Lock Dual Catch Can Kit - Cadillac CTS-V 2009-2015

Radium Engineering SKU: RAD20-1564-FL
Price
Regular price $503.45
Regular price $529.95 Sale price $503.45
5% OFF
Only 2 Left in Stock – Order Soon
Make sure this fits your vehicle Select your vehicle to confirm fitment before you order. Check
Shipping calculated at checkout.

Details

BrandRadium Engineering
SKURAD20-1564-FL
Manufacturer Part Number20-1564-FL

Product Information

A direct-fit dual catch can kit for the supercharged LSA CTS-V that combines the PCV kit 20-1562-FL and the CCV kit 20-0563-FL. The PCV can runs between the PCV valve and the intake manifold with a baffled oil cap and aluminum PCV valve replacing the restrictive factory orifice, and the CCV can mounts to three factory threaded bosses at the rear of the supercharger housing. Each can holds 7 fl oz with 2-step baffling, 10AN ORB inlet and outlet ports, a 4AN ORB drain and an O-ring sealed dipstick.

Specifications

Type Dual oil catch can kit
Series Fluid Lock
Circuit Dual (PCV and CCV)
Vent Type Vents to engine (closed system)
Can Type Fluid Lock (standard)
Material Aluminum
Capacity 7 fl oz per can
Ports 10AN ORB inlet and outlet, 4AN ORB bottom drain
Baffling 2-step oil separation baffling, O-ring sealed integrated dipstick
Hose / Fitting Size AN adapter fittings and hose ends
What's in the Box
  • Two baffled oil catch cans
  • Replacement baffled oil cap
  • O-ring sealed aluminum PCV valve
  • CTS-V mounting brackets
  • AN adapter fittings and hose ends
  • Stainless steel hardware
  • Radium PCV hose (contents of 20-1562-FL and 20-0563-FL)
Fitment Notes Sedan, coupe and wagon
Install Direct fit, no drilling; PCV bracket replaces the OEM intercooler coolant filler bracket, CCV can on 3 OEM bosses at the rear of the supercharger housing
Quantity 1
Warranty 1 year limited, from date of original purchase
Part Number 20-1564-FL

This part fits:

Year Make Model Submodel
2009-2014 Cadillac CTS-V Sedan
2011-2015 Cadillac CTS-V Coupe
2011-2014 Cadillac CTS-V Wagon

Documents: Installation Instructions (PDF)

What is the difference between the dual kit and the single kits?

  • The dual kit combines the PCV kit 20-1562-FL and the CCV kit 20-0563-FL, so both crankcase ventilation paths are filtered.

Which can fills faster?

  • PCV side cans typically collect more than CCV side cans.

How often does the catch can need to be emptied?

  • There is no set interval. Check the level with the integrated dipstick starting at 3 to 4 weeks of driving, then set your interval from what you find. Empty it by unscrewing the lower reservoir, or add the Catch Can Petcock Drain Kit where there is room under the can.

Is there a warranty?

  • Yes. Radium Engineering products carry a 1 year limited warranty from the date of original purchase against defects in materials and workmanship.
