Details
BrandSPL Parts
SKUSPPSPL TRE E9X
Manufacturer Part NumberSPL TRE E9X
Product Information
A pair of front tie rod ends with a relocatable pivot that corrects bump steer caused by modified caster or lower arm geometry. Stainless steel spacers move the pivot to set the correction, and on a car that is lowered a long way the new pivot height also stops the tie rod end from binding at full droop, which protects the inner tie rods from bending or breaking on track. Curved billet aluminum turnbuckles and PTFE-lined rod ends allow full suspension travel.
Specifications
| Type | Bumpsteer adjustable front tie rod ends |
| Position | Front |
| Adjustability | Bump steer: tie rod end pivot height set with stacked stainless steel spacers |
| Material | CNC machined 6061-T6 billet aluminum curved turnbuckles; titanium socket head cap screws; ASTM A574 socket head cap bolts |
| Bushing Material | FK rod ends with PTFE (Teflon) liners |
| Hardware Included | 1/4 in and 1/8 in thick stainless steel bump steer spacers with tapered ends |
| Fitment Notes | E8X 1 Series and M (2008-2013), E9X 3 Series (2006-2013), E90/E92 M3 (2008-2013), F22/F23 2 Series (through 2021), F30/F31/F32/F33/F34/F36 3 and 4 Series (through 2020), F80 M3, F82/F83 M4 (2014-2020) and F87 M2 (2016-2021). Also F20/F21 1 Series (non-US) |
| Quantity | Pair |
This part fits:
| Year | Make | Model | Submodel |
|---|---|---|---|
| 2011 | BMW | 1 Series M | Base |
| 2008-2013 | BMW | 128i | Base |
| 2008-2013 | BMW | 135i | Base |
| 2013 | BMW | 135is | Base |
| 2014-2016 | BMW | 228i | Base |
| 2015-2016 | BMW | 228i xDrive | Base |
| 2017-2021 | BMW | 230i | Base |
| 2017-2021 | BMW | 230i xDrive | Base |
| 2013-2018 | BMW | 320i | Base |
| 2013-2018 | BMW | 320i xDrive | Base |
| 2006 | BMW | 325i | Base |
| 2006 | BMW | 325xi | Base |
| 2014-2018 | BMW | 328d | Base |
| 2014-2018 | BMW | 328d xDrive | Base |
| 2007-2016 | BMW | 328i | Base |
| 2014-2016 | BMW | 328i GT xDrive | Base |
| 2009-2016 | BMW | 328i xDrive | Base |
| 2007-2008 | BMW | 328xi | Base |
| 2016-2018 | BMW | 330e | Base, iPerformance |
| 2006, 2017-2019 | BMW | 330i | Base |
| 2017-2019 | BMW | 330i GT xDrive | Base |
| 2017-2019 | BMW | 330i xDrive | Base |
| 2006 | BMW | 330xi | Base |
| 2009-2011 | BMW | 335d | Base |
| 2007-2015 | BMW | 335i | Base |
| 2014-2016 | BMW | 335i GT xDrive | Base |
| 2009-2015 | BMW | 335i xDrive | Base |
| 2011-2013 | BMW | 335is | Base |
| 2007-2008 | BMW | 335xi | Base |
| 2016-2018 | BMW | 340i | Base |
| 2017-2019 | BMW | 340i GT xDrive | Base |
| 2016-2018 | BMW | 340i xDrive | Base |
| 2014-2016 | BMW | 428i | Base |
| 2015-2016 | BMW | 428i Gran Coupe | Base |
| 2014-2016 | BMW | 428i xDrive | Base |
| 2015-2016 | BMW | 428i xDrive Gran Coupe | Base |
| 2017-2020 | BMW | 430i | Base |
| 2017-2020 | BMW | 430i Gran Coupe | Base |
| 2017-2020 | BMW | 430i xDrive | Base |
| 2017-2020 | BMW | 430i xDrive Gran Coupe | Base |
| 2014-2016 | BMW | 435i | Base |
| 2015-2016 | BMW | 435i Gran Coupe | Base |
| 2014-2016 | BMW | 435i xDrive | Base |
| 2015-2016 | BMW | 435i xDrive Gran Coupe | Base |
| 2017-2020 | BMW | 440i | Base |
| 2017-2020 | BMW | 440i Gran Coupe | Base |
| 2017-2020 | BMW | 440i xDrive | Base |
| 2017-2020 | BMW | 440i xDrive Gran Coupe | Base |
| 2013-2015 | BMW | ActiveHybrid 3 | Base |
| 2016-2021 | BMW | M2 | Base, Competition, CS |
| 2014-2016 | BMW | M235i | Base |
| 2015-2016 | BMW | M235i xDrive | Base |
| 2017-2021 | BMW | M240i | Base |
| 2017-2021 | BMW | M240i xDrive | Base |
| 2008-2013, 2015-2018 | BMW | M3 | Base |
| 2015-2020 | BMW | M4 | Base, CS, GTS |
Documents: Installation Instructions (PDF)
When are these needed?
- When caster or lower control arm geometry has been changed, the tie rods no longer follow the suspension arc and the car bump steers. They are also worth fitting on a car lowered far enough that the stock tie rod end binds at full droop.
Do they add noise or vibration?
- No. The tie rod ends are not a significant source of noise, vibration or harshness, and the reduced bump steer makes the car more predictable to drive.
Which factory parts do they replace?
- Known BMW part numbers are 32106767781, 32106767782, 32106799966 and 32106799967.
